REPLACEMENT PARTS LIST

When requesting service or ordering replacement parts, please quote the model type
and serial number. All parts listed in this manual may be ordered from a Bellfi res dealer.
No Article no
1 334842
2 334845
3 301907
4 301928
5 334841
6 334846
7 301909
8 334876
9 301915
10 301928
11 333597
12 302122
13 302084
14 302089
15 333607
16 333608
17 333610
18 333611
19 302086
20 333601
21 333602
22 341642
23 341644
24 302068
25 332025
26 334255
27 333604
70
Description
Main burner "Centre Fire" 1354 x 130 mm
Natural gas G20 / Butane/Propane G30/G31
G20: 1x Ø10.0 mm front + 1x Ø10.0 mm rear
+corner
G30/G31: 1x Ø20.0
1x Ø20.0 +corner
Burner mat L = 1354 mm "Centre Fire"
Burner injector (front+rear) Natural gas; no 225 (1x Ø2.25 mm)
Burner injector (front+rear) Butane/Propane; no 130 (1x Ø1.30 mm)
Main burner "Line Fire" 1354 x 130 mm
Natural gas G20 / Butane/Propane G30/G31
G20: 1x Ø8.0 mm front + 1x Ø8.0 mm rear
+corner
G30/G31: 1x Ø20.0
1x Ø20.0 +corner
Burner mat L = 1354 mm "Line Fire"
Burner injector Natural gas; Front: no 255 (1x Ø2.55 mm)
Burner injector Natural gas; Rear: no 210 (1x Ø2.10 mm)
Burner injector Butane/Propane; Front: no 150 (1x Ø1.50 mm)
Burner injector Butane/Propane; Rear: no 130 (1x Ø1.30 mm)
Gas regulator block; GV 60 (M10 Thermocouple connection)
3/8" male x Ø12 Compression fi tting
Nut Ø8 mm for burner supply GV 60 for "front burner"
Olive Ø8 mm for burner supply GV 60 for "front burner"
Gas valve "rear burner"
Adapter 3/8"bsp x 3/8"+ O-ring
Nut Ø8 mm for gas valve "rear burner"
Olive Ø8 mm for gas valve "rear burner"
Cut-off nipple Ø4 mm GV 60
Cable (sw): Receiver - Thermocouple interrupter, L = 500 mm
Cable (tc): Receiver - Thermocouple interrupter, L = 500 mm
Hand-held transmitter Symax 2 - EU - 8 buttons Bellfi res
Receiver Symax 2 - EU
8 Wire connecting cable Gas regulator block - Receiver, L = 500 mm
Piezo ignition cable, 2x
Thermocouple M10 - 2000 mm
Thermocouple interrupter
mm + 2x Ø5.0 mm front and
mm + 2x Ø5.0 mm rear
mm + 2x Ø5.0 mm front and
mm + 2x Ø5.0 mm rear
2.8 x 0.8 mm, L = 2000 mm
M10
