Bellfires VIEW BELL XXL 3 CF Installation Instructions & Manual For Maintenance page 71

No Article no
28 310908
29 310909
30 310910
31 310912
32 310907
33 302062
34 319842
35 332552
36 332553
37 326053
38 325949
39 325949
40 326055
41 326054
42 344617
43 333227
44 344618
45 342027
46 344335
47 301669
48 301593
49 319664
50 311006
51 301617
Installation instructions
Description
Pilot light set outer casing,
Packing pilot light set outer casing
Pilot light injector; Natural gas; no 36
Pilot light injector; Butane/Propane; no 23
Piezo electrode for pilot
Nut piezo electrode
Nut thermocouple
Pilot light olive; Ø4 mm, steel
Pilot light nut; Ø4 mm, steel
Pilot light pipe; Ø4 mm, L = 2000 mm, Flexible,
Burner pipe; Ø8 mm, L = 2000 mm, Flexible,
"front burner"
Burner pipe; Ø8 mm, L = 2000 mm, Flexible,
"rear burner"
Nut; Ø8 mm, compression elbow main burner
Olive; Ø8 mm, compression elbow main burner
Glass View Bell XXL
Glass View Bell XXL
AR-Glass View Bell XXL 3 front (467 x 1737 x 4 mm)
AR-Glass View Bell XXL 3 side (467 x 328 x 4 mm)
Black mirror rear wall View Bell XXL 3 (429 x 1718 x 5 mm)
Tube ceramic glue
Black fi bre glass tape 15 x 3 mm, adhesive
Black fi bre glass tape 30 x 2 mm, adhesive
Black fi bre glass tape 20 x 2 mm, adhesive
Black fi bre glass cord Ø10 mm
Double fl ame
light, 2.8 x 0.5 mm
3 front (467 x 1737 x 4
3 side (467 x 328 x 4
Stainless steel
Stainless steel - 10 kW+,
Stainless steel - 10 kW+,
mm)
mm)
English
71
