Bellfires VIEW BELL XXL 3 CF Installation Instructions & Manual For Maintenance page 68

Model
Gas
Country
Product identifi cation no
Type of appliance under CE-norm
Category of appliance
Nominal heat input
(Gross calorifi c value)
Nominal heat output
Effi ciency class
NOx-class
Gas rate (max.)
Supply pressure
Burner pressure (max.) Hot
Burner pressure (max.) Cold
Burner pressure (min.)
Primary air inlet burner Rear
Primary air inlet burner Front
Gas regulator block (remote control)
Main burner
Main burner injector Rear
Main burner injector Front
Pilot light burner
Pilot light burner injector
Gas connection
Concentric fl ue system connection
68
: VIEW BELL XXL 3 LF (Line Fire)
: NATURAL GAS
: GB; Great Britain/IE; Ireland
: 0063CM3684
: C / C / C
11 31 91
: I natural gas G20
2H
: 14.9 kW
: 11.4 kW
: 1 (85%)
: 5
: 1.43 m 3 /hr.
s
: 20.0 mbar
: 12.0 mbar(*)
: 11.3 mbar(**)
: 3.0 mbar(***)
: 1x Ø8.0 mm
: 1x Ø8.0 mm
: Mertik GV 60
: Line Fire 1354x130 mm
: no 210 (= 1x Ø2.10 mm)
: no 255 (= 1x Ø2.55 mm)
: SIT 0.145.019
: no 36 (SIT 0.977.091)
: 3/8" G / Ø12 mm
: Ø130 mm - Ø200 mm
English
: BUTANE / PROPANE
: GB; Great Britain/IE; Ireland
: 0063CM3684
: C / C / C
11 31 91
: I butane/propane G30/G31
3B/P
: Butane (G30) : 15.0 kW
Propane (G31) : 12.5 kW
: 9.6 - 11.5 kW
: 1 (85%)
: 5
: Butane (G30) : 1100 gr/hr.
Propane (G31) : 900 gr/hr.
: Butane (G30) : 37.0 mbar
Propane (G31) : 37.0 mbar
: 29.0 mbar(*)
: 29.0 mbar(**)
: 4.0 mbar(***)
: 1x Ø20.0 +corner mm +
2x Ø5.0 mm
: 1x Ø20,0 +corner mm +
2x Ø5.0 mm
: Mertik GV 60
: Line Fire 1354x130 mm
: no 130 (= 1x Ø1.30 mm)
: no 150 (= 1x Ø1.50 mm)
: SIT 0.145.019
: no 23 (SIT 0.977.150)
: 3/8" G / Ø12 mm
: Ø130 mm - Ø200 mm
Installation instructions
