Item descriptions:
see 1.6.2
Appliance:
View Bell XXL 3
Figure 8: Vertical chimney outlet using an existing unsound lined
chimney or when no chimney liners are present
(Flexible Ø100 mm / Ø150 mm)
ALL SIZES INCLUDE THE LENGTH OF THE ROOF OR WALL TERMINATION
Installation instructions
32
31
29
Y
27
28
29
4
1
18
30
29
6
8
7
26
29
100
Assemble restriction plate:
Distance Y Concentric connection
(min.-max.) on appliance
2.0 - 4.0 m Width: B = 50 mm
4.0 - 12.0 m Width: B = 65 mm
English
is Ø130-Ø200 mm
