REPLACEMENT PARTS LIST

When requesting service or ordering replacement parts, please quote the model type
and serial number. All parts listed in this manual may be ordered from a Bellfi res dealer.
No Part no
1 3.........
2 3.........
3 301915
4 334874
5 301928
6 301915
7 334874
8 340430
9 340431
10 340431
11 340430
12 340431
13 333605
14 333912
15 333606
16 333748
17 340469
18 340089
19 340091
84
Description
Main burner "Premium Fire" 600 x 240 mm
Natural gas G20 / Butane/Propane G30/G31
G20: Ø6.0 mm Left-Rear
Ø3.5 mm Left-Front
Ø6.0 mm Middle-Front
Ø6.0 mm Right-Rear
Ø3.5 mm Right-Front
G30/G31: Ø14x8 mm Left-Rear
Ø14x8 mm Left-Front
Ø15x8 mm + 2x Ø3.5 mm Middle-Front
Ø14x8 mm Right-Rear
Ø14x8 mm Right-Front
Main burner injector Natural gas; Left-Rear: Ø1.50 mm
Main burner injector Natural gas; Left-Front: Ø1.20 mm
Main burner injector Natural gas; Middle-Front: Ø1.30 mm
Main burner injector Natural gas; Right-Rear: Ø1.50 mm
Main burner injector Natural gas; Right-Front: Ø1.20 mm
Main burner injector Butane/Propane; Left-Rear: Ø0.80 mm
Main burner injector Butane/Propane; Left-Front: Ø0.75 mm
Main burner injector Butane/Propane; Middle-Front: Ø0.75 mm
Main burner injector Butane/Propane; Right-Rear: Ø0.80 mm
Main burner injector Butane/Propane; Right-Front: Ø0.75 mm
Module 230V AC (Light)
Fuse T 2.5A 250V Module
5-Pole cable Receiver - Module
Ambient lighting lamp 230V AC, E14, 25W
Log set (14 part) Natural gas / Butane/Propane
incl. embers and decorative ash
'Fire Glass' Dark Amber (2.5 kg)
'Fire Glass' Black (1.0 kg)
