The appliance can be fi tted with a convection package as an optional extra. This is a
"convection jacket" (convection casing) for around and above the appliance, two fl exible
aluminium pipes and two built-in convection vents. This enables hot air to be circulated
into the room.
If required, two additional convector grills can be fi tted (= 1x extra convection set).
If an existing chimney is to be used, please consult your installer fi rst. If the chimney
was previously used for a wood or coal fi re, then it should be cleaned by an expert.
1.2 CONCENTRIC FLUE SYSTEMS Ø100 MM - Ø150 MM AND
Ø130 MM - Ø200 MM: • Bellfi res
The gas fi re, in combination with the concentric fl ue system [Ø100 mm - Ø150 mm]
and/or [Ø130 mm - Ø200 mm] (rigid and/or fl exible) for the brand types mentioned
above, has been approved in accordance with the European CE-norm for gas
appliances and may therefore be used only with these systems.
The permitted components for these systems are listed in instructions enclosed:
CONCENTRIC COMPONENTS SUITABLE FOR THE INSTALLATION OF A
BELLFIRES GAS FIRE WITH CLOSED COMBUSTION. The guarantee on the
appliance lapses if it is installed, fully or partially, with other components or a different
fl ue system.
The concentric fl ue [Ø100 mm - Ø150 mm] and [Ø130 mm - Ø200 mm] systems can
be used with either a newly-built or existing chimney.
IMPORTANT
Observe the installation instructions, which are supplied
with the components of the concentric fl ue system.
8
- Muelink & Grol System
• Poujoulat - DUOGAS System
• Ontop - Metaloterm US System
• Jeremias/STB - H-Twin System (STB = Schoorsteen
• Jeremias - TWIN-GAS System
Techniek Brummen NL)
