1.7.5.2 Marble pebbles
1 Place the ceramic mat on the burner in such a way that the holes in the mat are in
line with the burner openings.
2 Spread the pebbles over the whole burner bed (burner and grid around the burner).
Make sure that the pilot light remains free.
View Bell XXL 3 CF/LF : see fi gure 26 and 27
: Marble pebbles must
not be placed on the
burner orifi
Figure 26: Marble pebbles-set natural gas and propane/butane-burner
Installation instructions
ces!
IMPORTANT: Open area, in order
to ensure free
accessibility of the
pilot fl ame to the burner
English
47
