2 CONFIGURATION

To begin with the parameterisation process of the device, it is necessary, once the ETS
program has been opened, to import the database of the product. Next, the device
should be added to the project where desired.
The configuration of this device is done both in the parameters tab and in the ETS
properties. The following sections explain how to configure each of the device
functionalities.

2.1 KNX TO IP INTERFACE

ALLinBOX is an interface device intended for the interconnection between a KNX bus
and an Ethernet network (LAN).
The network parameters can be configured in the "IP" panel of the ETS "Properties":
Obtain an IP address automatically
address whenever there is a DCHP server in the local network to which it is
connected.
2
The default values of each parameter will be highlighted in blue in this document, as follows:
[default/rest of options].
https://www.zennio.com
Figure 3 IP Configuration
2
. ALLinBOX will automatically take an IP
