2.10 SCENE TIMING

The scene timing enables the imposition of delays over the scenes of the outputs.
These delays, defined in parameters, are applied on the execution of one or more
scenes that may have been configured.
Please bear in mind that, as multiple delayed scenes can be configured for each
individual output / shutter channel / fan coil module, in case of receiving an order to
execute one of them when a previous temporisation is still pending for that output /
channel / module, such temporisation will be interrupted and only the delay and the
action of the new scene will be executed.
ETS PARAMETERISATION
Prior to setting the scene timing, it is necessary to have one or more scenes configured
in some of the outputs. When entering the Configuration window under Scene Timing, all
configured scenes will be listed, together with a few checkboxes to select which of them
need to be temporised, as shown in Figure 14:
Figure 14. Scene Timing
Enabling a certain Scene Number n [disabled/enabled] brings a new tab with such
name to the menu on the left, from which it is possible to configure the temporisation of
that scene for each of the outputs where it has been configured.
