1 Byte O C R - T - DPT_Fan_Stage
1 Byte I C - W - U DPT_Scaling
1 Byte I C - W - U DPT_Scaling
1 Byte I C - W - U DPT_Scaling
1 Byte O C R - T - DPT_Scaling
1 Byte O C R - T - DPT_Scaling
1 Byte O C R - T - DPT_Scaling
1 Byte I C - W - U DPT_Scaling
1 Byte I C - W - U DPT_Scaling
1 Byte I C - W - U DPT_Scaling
1 Byte I C - W - U DPT_Scaling
1 Bit I C - W - U DPT_OpenClose
1 Bit I C - W - U DPT_Switch
1 Bit I C - W - U DPT_OpenClose
1 Bit I C - W - U DPT_Switch
1 Bit O C R - T - DPT_OpenClose
1 Bit O C R - T - DPT_Switch
1 Bit O C R - T - DPT_OpenClose
1 Bit O C R - T - DPT_Switch
1 Bit O C R - T - DPT_OpenClose
1 Bit O C R - T - DPT_Switch
1 Bit O C R - T - DPT_Switch
1 Bit O C R - T - DPT_Switch
[FCx] Fan: Speed Enumeration
0 - 255
(Status)
[FCx] Manual Fan: Percentage
0% - 100%
Control
[FCx] Manual Fan: Percentage
0% - 100%
Control
[FCx] Manual Fan: Percentage
0% - 100%
Control
[FCx] Fan: Speed Percentage
0% - 100%
(Status)
[FCx] Fan: Speed Percentage
0% - 100%
(Status)
[FCx] Fan: Speed Percentage
0% - 100%
(Status)
[FCx] Cooling Fan: Continuous
0% - 100%
Control
[FCx] Cooling Valve: PI Control
0% - 100%
(Continuous)
[FCx] Heating Fan: Continuous
0% - 100%
Control
[FCx] Heating Valve: PI Control
0% - 100%
(Continuous)
[FCx] Cooling Valve: Control
0/1
Variable (1 bit)
[FCx] Cooling Valve: Control
0/1
Variable (1 bit)
[FCx] Heating Valve: Control
0/1
Variable (1 bit)
[FCx] Heating Valve: Control
0/1
Variable (1 bit)
0/1 [FCx] Cooling Valve (Status)
0/1 [FCx] Cooling Valve (Status)
0/1 [FCx] Valve (Status)
0/1 [FCx] Valve (Status)
0/1 [FCx] Heating Valve (Status)
0/1 [FCx] Heating Valve (Status)
[FCx] Cooling Valve: Anti-Seize
0/1
Protection (Status)
[FCx] Valve: Anti-Seize Protection
0/1
(Status)
ALLinBOX 1612 v2 / 88 / 46 / Hospitality
S0 = 0; S1 = 1
S0 = 0%; S1 = 0,4-33,3%; S2 =
33,7-66,7%; S3 = 67,1-100%
S0 = 0%; S1 = 1-50%; S2 = 51-
100%
S0 = 0%; S1 = 1-100%
S0 = 0%; S1 = 33,3%; S2 =
66,6%; S3 = 100%
S0 = 0%; S1 = 1-50%; S2 = 51-
100%
S0 = 0%; S1 = 1-100%
0 - 100%
0 - 100%
0 - 100%
0 - 100%
0 = Open Valve; 1 = Close Valve
0 = Close Valve; 1 = Open Valve
0 = Open Valve; 1 = Close Valve
0 = Close Valve; 1 = Open Valve
0 = Open; 1 = Closed
0 = Closed; 1 = Open
0 = Open; 1 = Closed
0 = Closed; 1 = Open
0 = Open; 1 = Closed
0 = Closed; 1 = Open
0 = Not Active; 1 = Active
0 = Not Active; 1 = Active
