2.12 MANUAL CONTROL THROUGH IR REMOTE CONTROL

ALLinBOX enables the manually switching the state of its output relays through the
pushbuttons of an IR remote control. A specific pushbutton on the IR remote control is
therefore available per output.
Manual operation has the mode, named as Test On Mode (for testing purposes during
the configuration of the device). From ETS it will be possible to configure if the manual
control will be available. Moreover, it is possible to enable a specific binary object for
locking and unlocking the manual control in runtime.
Note:
Switching to the Test On mode (unless disabled by parameter) needs to be
done by long pressing the Prog/Test button (for at least three seconds), until
the LED is no longer red and turns yellow. From that moment, once the button
is released, the LED light will remain green to confirm that the device is in Test
On mode. After that, an additional press will turn the LED yellow and then off,
once the button is released. This way, the device leaves the Test On mode.
Note that it will also leave this mode if a power failure takes place.
Test On Mode
https://www.zennio.com
Figure 16. IR Remote Control
