Programmer - Zennio ALLinBOX 1612 v2 User Manual

Use a static IP address. If DHCP protocol is not used, the following properties
must be set manually:
➢ IP Address [0.0.0.0...255.255.255.255].
➢ Subnet Mask [0.0.0.0...255.255.255.255].
➢ Default Gateway [0.0.0.0...255.255.255.255].
Note: If a static IP is configured, it is important to make sure that no other
device on the network has this IP assigned to it and that it does not belong to
the DHCP range configured for the router, otherwise connection problems with
the ALLinBOX will be observed.
In addition, the following information will be shown:
MAC Address.
Multicast Address [224.0.23.12]: IP address (reserved by the IANA
organization for the KNXnet/IP protocol) used by ETS in this case, for
discovering the available KNX-IP interfaces within the same network.
Once these properties have been entered an ETS programming is required to download
the configuration to the device.

2.2 PROGRAMMER

ALLinBOX can be used in ETS as a programming interface. In addition to an IP
address, they must be assigned a KNX individual address for this purpose.
Up to five simultaneous connections are allowed for performing downloads or for bus
monitoring.
Note: to detect the ALLinBOX as a programmer in ETS, it needs to be connected to the
same IP network as the PC.
To use a device as a programmer simply select it in the ETS "Bus" tab under
Connections → Interfaces.
