For detailed information about the functionality and the configuration of the related
parameters, please refer to the following specific manuals, all of them available under
the ALLinBOX product section at the Zennio homepage (www.zennio.com):
Individual outputs.
Shutter channels.
'Relays' Fan coil.

2.6.2 ALLINBOX Hospitality

ALLinBOX Hospitality incorporates one block of relay outputs to control a fan coil
module and one additional individual binary output.
The fan coil module is intended to operate the relay that open and close a water pipe
valve (one on-off valve only), and the relays that set the fan speed level. The latter can
be achieved through relay accumulation (more relays closed means a higher fan
speed) or through relay commutation (one specific relay will be available per level),
depending on the configuration.
The individual output provides an independent binary control of a load and offers many
different options like timers, alarms, lock, etc.
For detailed information about the functionality and the configuration of the related
parameters, please refer to the following specific manuals, all of them available under
the ALLinBOX product section at the Zennio homepage (www.zennio.com):
Individual outputs.
'Relays' Fan coil.
https://www.zennio.com
Figure 12. ALLinBOX Hospitality outputs screen.
