ETS PARAMETERISATION
Once the Master Light function has been enabled, a specific tab will be included in the
menu on the left. This new parameter screen (Figure 13) contains the following options:
Number of State Objects [1...12]: defines the number of 1-bit status objects
required. These objects are called "[ML] Status Object n".
In addition, the general status object ("[ML] General status") will always be
available in the project topology. It will be sent to the bus with a value of "1"
whenever there is at least one of the above state objects with such value.
Otherwise (i.e., if none of them has a value of "1"), it will be sent with a value of
"0".
Trigger Value [0 / 1 / 0/1]: sets the value that will trigger, when received
through "[ML] Trigger", the master action (the general switch-off or the
courtesy switch-on).
General Switch-Off.
➢ Delay [0...255] [x 1 s]: defines a certain delay (once the trigger has been
received) before the execution of the general switch-off.
➢ Binary Value [disabled/enabled]: if checked, object "[ML] General Switch-
off: Binary Object" will be enabled, which will send one "0" whenever the
general switch-off takes off.
https://www.zennio.com
Figure 13. Master Light
