Note: if this button is held while plugging the device into the KNX bus, the
device will enter into safe mode. In such case, the LED will blink in red every
0.5 seconds.
Outputs (16): output ports for the insertion of the stripped cables of the
systems being controlled by the actuator (see section 2.6). Please secure the
connection by means of the on-board screws.
Inputs (10): input ports for the insertion of the stripped cables of external
elements such as switches / motion detectors / temperature probes, etc. One
of the two cables of each element need to be connected to one of the slots
labelled "1" to "12" / "1" to "8" / "1" to "6", while the other cable should be
connected to the slot labelled as "C". Note that all the external input devices
share the "C" slot for one of the two cables. Please secure the connection by
means of the on-board screws.
LEDs (2, 3, 5, 7, 8 y 9) and reset buttons (4 y 6): the behaviour will be
described in section 1.4.
Main Power Supply (1): slots for the connection of the voltage wires (phase,
neutral and ground).
To get detailed information about the technical features of this device, as well as on the
installation and security procedures, please refer to the corresponding Datasheet,
bundled with the original package of the device and also available at www.zennio.com.
