2 CONFIGURATION

2.1 GENERAL

After importing the corresponding database in ETS and adding the device into the
topology of the desired project, the configuration process begins by right-clicking into
the device and selecting Edit parameters.

ETS PARAMETERISATION

The only parameterisable screen available by default is General. From this screen it is
possible to activate/deactivate all the required functionality.
Once activated, Inputs, Outputs, Logical Functions, Thermostats and
Master Light bring additional tabs to the menu on the left. These functions
and their parameters will be explained in later sections of this document.
Sending of Indication Objects (0 and 1) on Bus Voltage Recovery: this
parameter lets the integrator activate two new communication objects ("Reset
0" and "Reset 1"), which will be sent to the KNX bus with values "0" and "1"
respectively whenever the device begins operation (for example, after a bus
power failure). It is possible to parameterise a certain delay to this sending (0
to 255 seconds).
http://www.zennio.com
Figure 2. General screen
