Hardware Installation and Reference Guide
Note
The nameplate is located at the bottom of the product.
1.3

Package Contents

Table 1-2 Package Contents
No. Item
1 Access point
2 Mounting bracket
3 T8 Torx screw
4 Phillips pan head screws M4 × 40 mm
5 Warranty card
6 User manual
1.4

Technical Specifications

1.4.1

Dimensions and Weight

Table 1-3 Dimensions and Weight
Item
Physical Dimensions (W × H
× D)
Weight
Installation
Color
Lock Option
Mounting Bracket
Dimensions
(W × H × D)
Mounting Hole Pattern
Mounting Hole Diameter
RG-AP180P-L
86 mm × 170 mm × 43 mm (3.39 in. × 6.69 in. × 1.69 in.)
Main unit: 0.3 kg (0.66 lbs.)
Mounting bracket: 0.1 kg (0.22 lbs.)
Mounted in a 86-mm and concealed junction box of the American and
European standards or on a wall
White
Kensington lock
86 mm × 170 mm × 9 mm (3.39 in. × 6.69 in. × 0.35 in.)
60 mm (2.36 in.) or 83.5 mm (3.29 in.)
4.3 mm × 6.6 mm (0.17 in. x 0.26 in., oval)
5
Product Introduction
Quantity
1
1
1
2
1
1
