Hardware Installation and Reference Guide
Item
Receive Sensitivity
1.4.3

Port Specifications

Table 1-5 Port Specifications
Item
Bluetooth
Fixed Service Port
Fixed Management Port
Status LED
Button
1.4.4

Power Supply and Consumption

Table 1-6 Power Supply and Consumption
Item
Input Power Supply
Power Supply to External
Device
RG-AP180P-L
802.11b: –91 dBm (1 Mbps), –90 dBm (5 Mbps), –87 dBm (11 Mbps)
802.11a/g: –89 dBm (6 Mbps), –82 dBm (24 Mbps), –78 dBm (36 Mbps), –72
dBm (54 Mbps)
802.11n: –85 dBm@MCS0, –67 dBm@MCS7
802.11ac: VHT20: –85 dBm (MCS0), –62 dBm (MCS8)
802.11ac: VHT40: –82 dBm (MCS0), –57 dBm (MCS9)
802.11ac: VHT80: –79 dBm (MCS0), –53 dBm (MCS9)
802.11ax: HE80: –79 dBm (MCS0), 53 dBm (MCS9), –52 dBm (MCS11)
802.11ax: HE160: –79 dBm (MCS0), –53 dBm (MCS9), –50 dBm (MCS11)
RG-AP180P-L
Bluetooth 5.1
Uplink:
1 x 10/100/1000/2500Base-T Ethernet port with auto-negotiation, supporting
IEEE 802.3af/at-compliant PoE power supply. The LAN1 port is disabled for
external power supply when the AP works in IEEE 802.3af power supply mode.
Downlink:
4 x 10/100/1000Base-T Ethernet ports with auto-negotiation. The LAN1 port
can provide 48 V/10 W PoE power to external devices.
1 × Micro USB console port
One system LED
One reset button
RG-AP180P-L
(1) DC power supply (DC input voltage and current: 48 V/0.6 A)
(2) PoE/PoE+ power supply, compliant with the 802.3af/at standards
PoE power supply (48 V/10 W)
7
Product Introduction
