SMC Networks ISA3-FCP-4LB-L1 Operation Manual page 58

Delay time setting
Set the delay time referring to the setting method on
page 48.
Press the SET button to set.
Display colour setting
Press the UP or DOWN button to select the display colour.
Press the SET button to set.
∗1: Selected item becomes valid after pressing the SET button.
∗2: After enabling the setting by pressing the SET button, it is possible to return to the measurement mode by keeping pressing the
SET button for 2 seconds or longer.
When OUT port side pressure
is selected: [EdH2]
When SUP port side pressure
is selected: [SdH2]
When OUT port side pressure
is selected: [EdL2]
When SUP port side pressure
is selected: [SdL2]
Move on to display colour
setting.
[F 2] Setting of OUT2 completed
-57-
Return to function selection mode.
4 How to use
No.PS※※-OMW0009-C
