■[F 1] Setting of OUT1
The setting of output OUT1 can be performed.
Please refer to page 44
<Operation>
Press the UP or SET button in function selection mode to display [F 1].
Output setting
In OUT1, items other than the distance detection cannot be selected.
Output mode setting
Press the UP or DOWN button to select the required output mode.
Press the SET button to set.
Reversed output setting
Press the UP or DOWN button to select the reversed output.
Press the SET button to set.
for the relationship between the set items and operation.
Press the SET button.
Press the SET button.
Move on to output setting.
Move on to output mode setting.
Move on to reversed output setting.
Move on to switch point (distance) setting.
