OPERATION MANUAL
PRODUCT NAME:
MODEL:
○ Read this operation manual carefully to
understand before installation and operation.
○ Pay extra attention on the clause concerning the
safety.
○ Keep this operation manual available whenever
necessary.
Ionizer
IZN10 Series
- 1 -
※－
Doc. No. IZ
OML0002-C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IZN10 Series and is the answer not in the manual?

Questions and answers

Related Manuals for SMC Networks IZN10 Series

Summary of Contents for SMC Networks IZN10 Series

  • Page 1 Doc. No. IZ OML0002-C OPERATION MANUAL Ionizer PRODUCT NAME: MODEL: IZN10 Series ○ Read this operation manual carefully to understand before installation and operation. ○ Pay extra attention on the clause concerning the safety. ○ Keep this operation manual available whenever necessary.

  • Page 2: Table Of Contents

    INDEX 1. Safety Instructions・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 2. Specifications ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 3. How to Order・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 4. Mounting 4-1. Precautions for mounting・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 4-2. How to mount・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 4-3. Wiring table・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 4-4. Power supply cable wiring diagram・・・・・・・・・・・・・・・・・・・・・・・・・ 4-5. Timing chart・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 5. Functional Explanations ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 6. Outline Dimensions・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 7.

  • Page 3: Safety Instructions

    1. Safety instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard by labels "Caution," "Warning" and "Danger" to ensure safety. be to observe ISO4414, JIS B8370 and other safety precautions. CAUTION Operator error could result in injury or equipment damage.
  • Page 4 Selection WARNING 1. The ionizer (hereinafter referred to as the “product”) is intended to be used for the general FA devices. If other applications (especially those indicated in 4 on page 2) are used, contact SMC before use. 2. Use under specified voltage and temperature. Voltage out of specification may cause malfunction, breakage, electric shock or fire.

  • Page 5: Specifications

    2. Specifications Model number of ionizer IZN10-□□ IZN10-□□P (NPN) (PNP) Ion generating method Corona discharge type Voltage applying method High frequency AC type Note 1) Discharge output 2500V Note 2) Ion balance ±10 V at max. 0.03 ppm (0.05 ppm for energy saving charge Note 3) Ozone generated amount elimination nozzle）...

  • Page 6: How To Order

    3. How to Order IZN10 - 01 Z - B1 Series name IZN10 High frequency AC nozzle type Nozzle shape Type Energy saving charge elimination nozzle Large flow nozzle Piping female Note 1) Rc1/8 Output specification Piping diameter f6: metric f6.35 （...

  • Page 7: Mounting

    4. Mounting 4-1. Precautions for mounting Mounting WARNING 1. Provide required space for maintenance, wiring and piping at installation. Install connector and One-touch fitting for air supply to allow removal and mounting of cable and tube. Do not bend cable and tube at steep angles. Affix them straight, within the minimum bending radius to prevent applying stress to the installation base of the connector and One-touch fitting.
  • Page 8 charge elimination, and the charge-elimination effect can decrease. Wiring and piping WARNING 1. Check that power supply capacity is enough and voltage meets specification before piping. 2. Always use a UL listed/recognized power supply that is a class-2 power supply with DC 24 V and under 2.1 A. 3.

  • Page 9: How To Mount

    4. Environment to avoid Do not use or store under the following environments, as these may cause operation failure. If it is unavoidable, take the appropriate measures. a. Where ambient temperature exceeds 0 to 50 b. Where ambient humidity exceeds 35 to 65% RH. c.
  • Page 10 4-2-2 Mounting When mounting the product, use a M3 hexagon socket head bolts. Tightening torque is 0.61 to 0.63 Nm. 1) Body mounting tap or through hole Referring to the figure below, affix the product using hexagon socket head bolts with optimum length. Use a bolt with a max.
  • Page 11 Outward mounting of L-bracket 1. Prepare hexagon socket head bolts (M3 X 6) and washers attached to the product and mount the L-bracket. 2. Adjust the product to the desired mounting angle referring to figure 3 and fix it. For the oval hole, use the washer attached to the product.
  • Page 12 Inward mounting of L-bracket 1. Before mounting the product, mount the L-bracket where the product will be installed. The mounting angle of the bracket can be adjusted in the following range. Hexagon socket head bolts are not included with the product and need to be prepared separately. 2.
  • Page 13 4) DIN rail mounting bracket 1. Adjust the L-bracket to the desired angle and fix it. 2. Mount the L-bracket to the product with the hexagon socket head bolts (M3 X 6) and washers attached to the product. 3. Mount the product to the DIN rail and tighten the socket head bolts to fix it. Fixing hexagon socket head bolt - 13 -...
  • Page 14 5) Mounting 1. Insert the spacers between the counter bores of the body. 2. Hold the product by L-brackets from both ends and tighten the hexagon socket head bolts. Tightening torque is 0.61 to 0.63Nm. The composition of parts to connect 3 ionizers is shown below. Fixing hexagon socket head bolt M3 L-bracket DIN rail mounting bracket...

  • Page 15: Wiring Table

    4-3.Wiring table Necessity Signal name Specification of wiring Power Brown supply +24 ― ― ○ Power Blue ― ― ○ supply GND Discharge Orange Input When the signal is turned off, discharge stops. ○ stop signal When the signal is turned on and then off, the error signal is reset.

  • Page 16: Power Supply Cable Wiring Diagram

    4-4. Power supply cable wiring diagram ■　ＮＰＮ ■　PNP Ionizer Ionizer Brown +24V +24V ＋ Power supply　　　　 Brown +24V +24V ＋ Power supply　　 Blue GND GND DC24V±10% Blue GND GND DC24V±10% ＰＬＣ ＩＮＰＵＴ ＰＬＣ OUTPUT ＩＮＰＵＴ OUTPUT Orange Discharge stop signal Orange Discharge stop signal Pink Reset signal Pink Reset signal...

  • Page 17: Functional Explanations

    5. Functional Explanation 1. Detection of dirt on electrode needle During operation reduced charge elimination capability due to a dirt or wear on electrode needles is monitored continuously. If it becomes necessary to clean the electrode needle, the LED for maintenance lights up on the display of the product and maintenance output signal is generated.

  • Page 18: Outline Dimensions

    6. Outline Dimensions IZN10-01 / IZN10-02 Energy-saving nozzle / Large-flow nozzle - 18 -...

  • Page 19: Maintenance

    7. Maintenance 7-1. Precautions for maintenance Maintenance WARNING Caution 1. Keep electrode needle clean with regular maintenance. for High Voltage Make sure that the product is operating without any failure with regular A high voltage generating circuit is maintenance. Only those with proper knowledge and experience should installed.

  • Page 20: How To Maintain Electrode Needle

    7-2. How to maintain electrode needles 7-2-1. Cleaning of electrode needles 1) Disconnect the power supply cable. 2) Rotate the locked knob and pull down the cartridge. 3) Clean electrode needles. 4) Mount the cartridge and power supply cable in the reverse order to complete the cleaning. ②...
