○Connector pin No. (Lead wire side)
•ZS-31-B (Lead wire with connector)
•ZS-31-C (Lead wire with connector)
Connector pin No.
Lead wire colour
1
2
3
4
-36-
Description
Brown
DC(+)
White
OUT2
Blue
DC(-)
Black
OUT1(C/Q)
3
Installation
No.PS※※-OMW0009-C
