ORDERING INFORMATION

BILL OF MATERIALS

Table 6. Bill of Materials
Quantity Designator
1 A1
4 C1, C9, C35, C38
1 C10
2 C11, C14
3 C12, C13, C23
2 C4, C15
10 C2, C6, C7, C8, C16,
C34, C36, C39, C40,
C44
3 C5, C18, C19
1 C27
1 C54
1 D1
1 D2
5 E1, E2, E3, E4, E5
4 GND1, GND2, GND3,
GND4
3 J1, J3, J4
1 L1
1 L2
1 L3
1 P1
1 P14
analog.com
Description Value
180 MHz rail-to-rail input Not applicable
output amplifier
Ceramic capacitors, X7R, 1 μF
AC volt, low capacitance
change rate
Multilayer ceramic chip 4.7 μF
capacitor, X7R
Ceramic capacitors, X7R, 10 μF
for general use
Ceramic capacitors, X5R, 2.2 μF
general purpose
Ceramic capacitors, X7R, 2.2 μF
general purpose
Ceramic capacitors, 0603, 0.1 μF
X7R
Ceramic chip capacitors, 1 μF
X7R
Ceramic capacitor, X7S, 22 μF
general purpose
Ceramic capacitor, X5R, 3.9 μF
commercial grade
Diode Schottky power Not applicable
rectifier, surface-mount
device
Diode Schottky barrier Not applicable
Inductor chips, ferrite bead, 1000 Ω at 100 MHz
0.3 A, 0.39 Ω DC
resistance
PCB connectors, test point Not applicable
black
PCB connectors, Not applicable
Subminiature Version B,
jack ST
Shielded power inductor 10 μH
(not recommended for new
designs)
Shielded power inductor, 6.8 μH
1.5 A, 0.150 Ω DC
resistance
Shielded power inductor, 10 μH
0.729 A, 0.459 Ω maximum
DC resistance
PCB connector, signal-end Not applicable
male 160 position, for
Kitt RF application, use
alternate symbol
PCB connector, terminal Not applicable
black standard, 10 A, 3.81
mm pitch
EVAL-ADAQ7768-1
Manufacturer Manufacturer Part Number
Analog Devices ADA4807-1ARJZ-R7
KEMET C0603C105K8RACTU
TDK C2012X7R1E475K125AB
Murata GRM21BZ71E106KE15L
Murata GRM188R61H225KE11J
Murata GRM188R71A225KE15D
KEMET C0603C104K3RACTU
Murata GCM21BR71E105KA56L
TDK C2012X7S1A226M125AC
KEMET C0805C395K8PACTU
ON Semiconductor MBR0520LT1G
NXP Semiconductors 1PS79SB17
TAIYO YUDEN BK1608TS102-T
Keystone Electronics 5001
TE Connectivity Limited 1-1337482-0
Coilcraft Incorporated LPS4018-103MLB
Coilcraft Incorporated LPS4018-682MRB
Coilcraft Incorporated EPL2014-103MLB
Samtec ASP-134604-01
Camdenboss CTB0308/2
