User Guide
EVALUATION BOARD HARDWARE
Table 3. On-Board Connectors (Continued)
Connector
P14
J3/J4/P7
S1
S2
J1
analog.com
Function
Terminal block connector for external 3.3 V supply.
SMB and terminal block connector for analog inputs, IN+ and IN–.
ADC reset switch
Mechanical switch for PGIA Gain and FDA power mode control.
SMB connector for the external MCLK.
EVAL-ADAQ7768-1
Rev. 0 | 9 of 33
