User Guide
ORDERING INFORMATION
Table 6. Bill of Materials (Continued)
Quantity Designator
1 P5
1 P7
1 R1
13 R9, R12, R13, R14,
R15, R37, R40, R49,
R52, R56, R58, R60,
R65
5 R5, R6, R7, R16, R17
1 R2
1 R24
2 R25, R26
1 R28
5 R29, R30, R31, R32,
R33
1 R3
6 R34, R41, R44, R45,
R46, R48
1 R4
2 R55, R66
1 R67
1 R8
1 S1
1 S2
1 U1
1 U2
1 U3
1 U4
1 U5
analog.com
Description Value
PCB connector, high Not applicable
dynamic range standard
male, peripheral module
PCB connector, term block, Not applicable
3 position
Precision resistor, thick film 105 kΩ
chip
Resistors, film, surface- 0 Ω
mount devices 0603
Resistors, standard thick 0 Ω
film chip
Resistor, standard thick 68.1 kΩ
film chip
Resistor, standard thick 10 kΩ
film chip, R0603
Resistors, general purpose 13 kΩ
chip
Resistor, chip, surface- 147 kΩ
mount device, 0603
Resistors, precision thick 20 kΩ
film chip
Resistor, precision thick 3.57 kΩ
film chip
Resistors, thick film chip 1 kΩ
Resistor, metal film high 300 kΩ
release
Resistors, metal film chip 1 kΩ
Precision resistor, thick film 100 kΩ
chip, R0603
Resistor, standard thick 100 kΩ
film chip, for automotive
Tactile switch, Not applicable
microminiature, top-
actuated, single-pole
single-throw (SPST)-NO
Smart switch, 5 position Not applicable
Non-synchronization step- Not applicable
down DC-DC
Dual-channel, low-noise, Not applicable
bias generators
Low-noise, linear regulator, Not applicable
adjacent output voltage
2
2 KB serial I C Not applicable
bus, electrically erasable
programmable read-only
memory (EEPROM), 1.8 V
to 5.5 V
24-bit, single-channel Not applicable
precision μModule data
EVAL-ADAQ7768-1
Manufacturer Manufacturer Part Number
Samtec TSW-106-08-G-D
Phoenix Contact 1727023
Panasonic ERJ-3EKF1053V
Panasonic ERJ-3GEY0R00V
Vishay CRCW06030000Z0EAHP
Panasonic ERJ-2RKF6812X
Panasonic ERJ-3EKF1002V
YAGEO RC0603FR-0713KL
Susumu Corporation Limited RR0816P-1473-D-17D
Panasonic ERJ-3EKF2002V
Panasonic ERJ-2RKF3571X
Multicomp (SPC) MC0063W060311K
Panasonic ERA-3AEB304V
Panasonic ERA-3AEB102V
Panasonic ERJ-3EKF1000V
Vishay CRCW0603100KFKEA
C & K Switches PTS830 GM140 SMTR LFS
CTS 219-5MST
Analog Devices ADP2300AUJZ-R7
Linear Technology LT3095IUDD#PBF
Analog Devices ADP7182ACPZN-R7
STMicroelectronics M24C02-RMN6TP
Analog Devices ADAQ7768-1BBCZ-V2
Rev. 0 | 31 of 33
