Chapter 1: Product Introduction
Item Function
VMC 100
•
•
•
11 Left Side I/O
VMC 1100
•
•
•
•
Wi-Fi Antenna
12
Connector
GPS Antenna
•
13
Connector
WWAN Antenna
•
14
Connector
DB15 female connector with GPIO/ADC/PWM.
15 Multi I/O Port
Copyright © 2014 NEXCOM International Co., Ltd. All rights reserved
USB 2.0
Mic-in
Line-out
USB 3.0
Mic-in
Line-out
The 2 external SMA type antenna mounting connectors are used to connect the antenna to a WLAN module and
Bluetooth.
The external SMA type antenna mounting connector is used to connect the antenna to a GPS module.
The external SMA type antenna mounting connector is used to connect the antenna to a WWAN module.
Pin Description
1 Speed 1
2 Speed 2
3 ADC 0
4 ADC 1
5 A_GND
6 GPI 1
7 GPI 2
VMC 100: GPI3
8
VMC 1100: MDI 1 (for tracker, SOS)
Description
Pin Description
9 GPO 1
10 GPO 2
VMC 100: GPO 3
11 VMC 1100: MDI 2 (for tracker,
release KEY)
12 DR GPS_IPPS
13 DR GPS_ODO
14 DR GPS_DIR
15 GND
13
