Appendix A: I/O Address Function
9. Startup and Shutdown Voltage Control
I/O port : 0EE8H
Only set by switch on motherboard(read only)
BIT3~2
Input Voltage
11
12V
10
24V
01
6~36V
00
6~36V
When input voltage 12V
BIT1~0
Input Voltage 12V
00
Startup
11.5V
01
Startup
12V
10
Startup
12.5V
11
Startup
12.5V
Copyright © 2014 NEXCOM International Co., Ltd. All rights reserved
When input voltage 24V
BIT1~0
Shutdown
00
10.5V
Shutdown
01
11V
Shutdown
10
11V
Shutdown
11
11.5V
Input Voltage 24V
Startup
Shutdown
23V
21V
Startup
Shutdown
24V
22V
Startup
Shutdown
25V
22V
Startup
Shutdown
25V
23V
82
VMC 100/1100 Series User Manual
