Chapter 1: Product Introduction
Item
Function
DB9 male connector with RS-232 or RS-485 and CAN bus.
16
Multi I/O Port
RJ-45 connector with RS-232 interface of either 0, 5 or 12V on pin 9 for external devices.
17
COM1
18
LAN Port
The LAN port is an RJ45 interface with integrated LEDs and supports 10/100/1000Mbps Ethernet data transfer rates.
Copyright © 2014 NEXCOM International Co., Ltd. All rights reserved
Description
Pin
Description
1
GND
2
RX/ RS-485+
3
RS-485-
4
TX
5
GND
6
CAN1 H
7
CAN1 L
8
CAN2 H
9
CAN2 L
Pin
Description
1
0/ 5/ 12V
2
RX
3
TX
4
DTR
5
GND
6
DSR
7
RTS
8
CTS
14
VMC 100/1100 Series User Manual
