Appendix A: I/O Address Function
6. WDT
I/O port: 0EE5H
Bit3: WDT DISABLE\ENABLE
0: DISABLE(*)
1: ENABLE
BIT 3, 2, 1, 0: time setting
BIT3~0 Time(sec)
0000 1(*)
0001 2
0010 4
0011 8
0100 16
0101 32
0110 64
0111 128
1000 256
Auto clear WDT timer when read/write I/O port 0EE5H.
Copyright © 2014 NEXCOM International Co., Ltd. All rights reserved
7. Onboard Module Disable/Enable(1)
I/O port : 0EE6H
Bit0: 3.5G MODULE
0: DISABLE
1: ENABLE (*)
Bit1: WLAN MODULE
0: DISABLE
1: ENABLE(*)
Bit2: EXTERNAL +12V power
0: DISABLE
1: ENABLE (*)
Bit3: By Pass Car battery power
0: DISABLE
1: ENABLE(*)
Bit4: Wake on 3.5G MODULE
0: DISABLE(*)
1: ENABLE
