WIFI Dongle Installation (Optional)
WIFI Dongle Installation Instructions
1. Remove the safety glass and firebox glass – see manual.
2. Remove the front lower firebox glass pad to allow access to the IFC cover.
3. Locate the 2 screws on the IFC cover and remove the cover to access the
IFC.
4. Locate the WIFI dongle connection (X0A) on the side of the IFC.
X0A
920-561
5. Line up the tabs on the dongle with the notches on the IFC connection
and insert the cable into the connection.
6. Apply Velcro strips to the bottom of the dongle and to the side of the
IFC bracket.
7. Place the dongle onto the IFC bracket.
8. Reverse steps 1, 2 and 3.
1
CITY SERIES 40
owner's information
City Series CV40E-12 |
19
06.29.22
