Regency CP50E Owners & Installation Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
CP50E DIRECT VENT
STYLE
Pier
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
- WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
Certified to/Certifié pour:
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
920-800
City Series ®
MODEL
CP50E-NG / CP50E-LP
CSA 2.17-2017
ANSI Z21.88-2019
CSA 2.33-2019
Installer: Please complete the details on the back cover and leave this
manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Owners &
Installation Manual
www.regency-fire.com
08.12.24

Advertisement

loading
Need help?

Need help?

Do you have a question about the CP50E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Regency CP50E

Summary of Contents for Regency CP50E

  • Page 1 City Series ® Owners & CP50E DIRECT VENT Installation Manual www.regency-fire.com STYLE MODEL Pier CP50E-NG / CP50E-LP WARNING FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
  • Page 2 The CP50E City Series have been approved by Intertek for both safety and efficiency. As it also bears our own mark, it promises to provide you with economy, comfort and security for many trouble free years to follow.

  • Page 3: Manufactured Mobile Home Requirements

    This appliance can only be used with the type of gas indicated on the rating plate. It is not convertible for use with other gases, unless a certified kit is used. Ensure that structural members are not cut or weakened during installation. City Series CP50E |...
  • Page 4 After it has been determined that each appliance connected to the venting system properly vents when tested as outlined above, return doors, windows, exhaust fans, fireplace damper and any other gas-fired burning appliance to the previous conditions of use. | City Series CP50E...

  • Page 5: Table Of Contents

    Horizontal Terminations - Rigid Pipe 5" x 8" (127 mm x 203 mm) ... 56 Horizontal Terminations - 5" x 8" (127 mm x 203 mm) Rigid or Flex Pipe ................... 57 Horizontal Venting with Two 90 Elbows ........57 City Series CP50E |...

  • Page 6: Copy Of Safety Decal

    Pour plus de détails , se reporter au Répertoire des produits de construction de Intertek. NATURAL GAS: Model: CP50E-NG Minimum Clearances to Combustibles / GAZ NATUREL : Modèle CP50E-NG Dégagements minimaux par rapport aux matériaux combustibles 5.0" WC/C.E. (1.25 kPa)

  • Page 7: Ma Code - Co Detector

    (e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipm ent, all venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the installation. City Series CP50E |...

  • Page 8: Owner's Information

    W I T H T H E M A N U F A C T U R E R ' S WARNING: FAILURE TO INSTALL THIS BARRIER FOR THIS APPLIANCE. APPLIANCE CORRECTLY WILL VOID YOUR WARRANTY AND MAY CAUSE A HOUSE FIRE. | City Series CP50E...

  • Page 9: First Fire

    This switch would have been positioned at time of install and should never have to be moved from one position to another. This switch is hidden to avoid the home owner having the switch in wrong position. City Series CP50E |...

  • Page 10: Lighting Procedure

    Turn the system off by pressing the ON/OFF button on the remote . as it will cause the power vent blower to run continuously. b) Wait 5 minutes, then repeat the process from step 2. | City Series CP50E...

  • Page 11: Copy Of The Lighting Plate Instructions

    DO NOT REMOVE THIS INSTRUCTION PLATE NE PAS ENLEVER CETTE ÉTIQUETTE D’INSTRUCTIONS 919-649b Part #: 919-649b City Series CP50E | Colours: Black on Grey, except for parts indicated as being Red. Punch out .25" hole top right corner where indicated.

  • Page 12: Proflame Ii Remote Control Operating Instructions

    REMOTE CONTROL Supply voltage 4.5V (three 1.5V AAA batteries) Ambient temperature rat- 0 - 50 C (32 - 122 ings Typical operative distance 12 m (39 ft) in free air Radio frequency 315 MHZ (FCC version) | City Series CP50E...

  • Page 13: Temperature Indication Display

    LCD display will only show the room temperature (Fig. 6). At the same time the IFC will turn off the appliance. A single “beep” from the IFC confirms reception of the command. Figure 9 Figure 10 City Series CP50E |...

  • Page 14: Smart Thermostat (Transmitter Operation)

    (Fig. 14). A single “beep” confirms reception of the command. the DOWN ARROW key will turn the secondary burner off. A single “beep” confirms the reception of the command. Figure 17 Figure 18 Figure 13 Figure 14 | City Series CP50E...

  • Page 15: Continuous Pilot/Intermittent Pilot (Cpi/Ipi) Selection

    "Maintenance" 2. Press and hold the ON/OFF and MODE buttons simultatneously. section. 3. Reinstall the battery removed in step 1 while holding both buttons, then release the MODE button only. City Series CP50E |...

  • Page 16: Proflame Ii Battery Holder Battery Replacement

    STEP 3 Keeping the battery compartment pressed in, close the left slide Close the right slide STEP 4 Reinstall wall cover plate with 2 Phillips head screws. | City Series CP50E...

  • Page 17: Maintenance Instructions

    In the event that you break your glass by impact, are listed below. purchase your replacement from an authorized Regency dealer only. Replacement glass is shipped 1. Check the venting system for corrosion in areas already installed into the door frame. Reinstall as per that are exposed to the elements.

  • Page 18: Installer's Information

    • All pictures/diagrams shown throughout this manual are for illustration purposes only. Actual product may vary due to enhancements. • Dimensions will appear as (inches)" / (metric) mm throughout this manual. The inches are rounded to the nearest 1/16" when converted. | City Series CP50E...

  • Page 19: Gas Connection - Bottom Of Unit

    (Metal box supplied for all 120 volt connections.) SIDE A SIDE B SIDE A SIDE B 6-1/4" (158 mm) 1-1/2" (38 mm) 1-13/16" (45 mm) 2-3/8" (60 mm) 1-3/8" (35 mm) 2-9/16" (64 mm) 13-9/16" (345 mm) City Series CP50E |...

  • Page 20: Gas Installation Checklist

    This general checklist does not contain all pertinent installation details or specifics and does not supersede the guidelines in this manual. Your Regency dealer/installer should use it in conjunction with manual instructions. Please follow all local codes and jurisdictions in authority.
  • Page 21 Was accessing unit controls in a power outage explained to the customer? Are the model and serial numbers and the date of installation of the unit written in the manual and on the checklist? Were the warranty and unit registration reviewed with the customer? Comments: City Series CP50E | 06/27/24...

  • Page 22: General Safety Information

    8. Make the gas connections and test the pilot. The configuration must be as per the diagram in servicing. Connection errors can the "Gas Line Installation" & "Pilot Adjustment" cause improper and dangerous sections. operation. Verify proper operation after servicing. | City Series CP50E...

  • Page 23: Locating Your Gas Fireplace

    Some locations may have further requirements - check local codes before installation. 6. The CP50E Direct Vent Gas Fireplace is approved for alcove installations which meet the clearances listed on this page. 7. We recommend that you plan your installation on...

  • Page 24: Unit Assembly Prior To Installation

    (6 per side). The handles can be recycled. Side Standoff Assembly The CP50E has four standoffs (2 on each side) that you must assemble before Side stando assembly CV60E installation. The standoffs are shipped flat. Fold the standoffs and install them by sliding the two tabs into the slots on the unit.

  • Page 25: Access Panel Removal

    3. Push the access panel toward the inside of the unit and lift up from the bottom to release the bottom tabs. When clear, lift out of unit. 4. Reverse steps to reinstall access panel. City Series CP50E |...

  • Page 26: Installation - General

    Transportation supports can be placed inside the unit. 4. If the inner ceramic end glass ever requires removal reverse steps to install transportation supports. Screw access behind the top face | City Series CP50E...

  • Page 27: Chase Enclosure

    Minimum 120 sq. in. opening (flush) Stud Stud In the example above, the ceiling does not meet the requirement as it is higher than the specified minimum. Top of chase enclosure is sealed off to meet the 0-2'' (51mm) requirement. City Series CP50E |...

  • Page 28: Clearances - Flush Installation

    • The top, back, and sides of the fireplace are defined by standoffs. The metal ends of the standoffs may NOT be recessed into combustible construction. Ceiling Sprinkler Chase grill Side view | City Series CP50E...

  • Page 29: Flush Installation Examples (Ventilation Openings)

    4" (102 mm) min. 10" (254 mm) min. 1-1/2" (38 mm) min. Option 2 - Front/Side Shown with ventilation openings on side and front (60 sq. in. each) to meet the minimum requirement of 120 sq. in. City Series CP50E |...
  • Page 30 Shown with ventilation opening on one side to meet the minimum requirement of 120 sq. in. Example: If the chase vent opening was 1-3/4" (44 mm) minimum in height, the minimum width must be 68-3/4” (1746 mm) in order to equal 120 sq in. | City Series CP50E...
  • Page 31 120 sq. in. Example : If the chase vent opening was 1-3/4" (44 mm) minimum in height, the minimum width must be 68-3/4” (1746 mm) in order to equal 120 sq in. City Series CP50E |...

  • Page 32: Clearances - Bench Installation

    • The top, back, and sides of the fireplace are defined by standoffs. The metal ends of the standoff may NOT be recessed into combustible construction. Ceiling Sprinkler Chase grill Side view | City Series CP50E...

  • Page 33: Bench Installation Examples (Ventilation Openings)

    Example 1: If each chase vent opening was 10” (254 mm) as the width, the height must be 8-3/4” (222 mm) order to equal 87.5 sq in. per ventilation opening Example 2: If each chase vent opening was 1-3/4” (44 mm) as the height, the width must be at least 50” (1270 mm) order to equal 87.5 sq in. per ventilation opening. City Series CP50E |...
  • Page 34 175 sq. in min. 1-3/4" (44 mm) min. 3" (77 mm) min. Option 4 - Top and Front Shown with ventilation opening on top and front (87.5 sq. in. each) to meet the minimum requirement of 175 sq. in. | City Series CP50E...
  • Page 35 Shown with ventilation opening on the front with a chimney chase to meet the minimum requirement of 175 sq. in. The chimney chase must be sealed with a firestop to prevent heat from escaping into the chimney chase enclosure. All heat must exit through the ventilation openings. City Series CP50E |...

  • Page 36: Mantel Clearances

    The clearances listed below are minimum requirements for either side of this see-through fireplace, unless otherwise noted. TOP OF FIREPLACE OPENING 12" (305 mm) maximum 9" (229 mm) 5-1/4" (133 mm) maximum 18" (457 mm) 1/2" Drywall, wood, wood panel, etc. | City Series CP50E...

  • Page 37: Mantel Leg Clearances

    The clearances listed below are minimum requirements for either side of this pier fireplace, unless otherwise noted. Mantel Leg 7" (179 mm) Allowable mantel leg projection 5" (127 mm) 12" (305 mm) 10" (251 mm) 9" (229 mm) City Series CP50E |...

  • Page 38: Framing Dimensions

    0.000 REF = REFERENCE ONLY UNITS IN INCHES ANGULAR = 1 E.C.N.: SIGN: DATE: THIS DRAWING IS THE PROPERTY OF FPI LTD., IT MAY NOT BE COPIED IN WHOLE OR IN PART, OR DISCLOSED TO A THIRD PAR | City Series CP50E...

  • Page 39: Chase Vent Installation (White Front) (Part # 482-991)

    Max 2” (51 mm) Top of chase enclosure Max 2” (51 mm) 51-1/2" (1308 mm) 50” (1270 mm) Chase Vent 51-1/2" (1308 mm) 50” (1270 mm) Chase Vent Stud Stud Finishing material Finishing material | City Series CV60E City Series CP50E |...

  • Page 40: Wall Board/Drywall Installation

    It is important to follow the framing and finishing instructions in this manual to ensure proper placement of the fireplace in the surrounding materials. Wall board materials 1/2 in. (13 mm) thick are specified in this manual to align with the optional finishing methods offered with this appliance. The CP50E may be finished to the appliance opening with 1/2 inch (13 mm) thick drywall.

  • Page 41: Framing And Finishing Inset Installations

    (with smaller glass) have no limit on how far the combustible material extends from the appliance. Ensure that no material encroaches anywhere in the area of the glass as defined by the finishing lip surrounding the appliance. City Series CP50E |...

  • Page 42: Typical Installations - Flush Tv Install

    IMPORTANT: Ensure that all electrical, Ethernet, HDMI, networking, optical, wires/cables, conduits, etc. are run through the wood or steel stud work. Do not place directly above or have exposed over the fireplace. | City Series CP50E...

  • Page 43: Typical Installations - Recessed Tv Install

    TV and the mounting bracket used. IMPORTANT: Ensure that all electrical, Ethernet, HDMI, networking, optical, wires/cables, conduits, etc. are run through the wood or steel stud work. Do not place directly above or have exposed over the fireplace. City Series CP50E |...

  • Page 44: Finishing

    Firebox Glass will not be Screwdriver and remove bottom and - Finish up to trim on all 4 sides possible side trim pieces - Bottom edge should be ush with top surface of Inner Liner Panel Recess Install Example | City Series CP50E...

  • Page 45: Wall Mount On / Off Switch And Battery Holder Installation

    Proflame Battery Holder REMOTE Item Part No. Description Slider Switch (included with wall plate) 911-335 Wall Plate - White 911-343 Wall Plate - Black 911-337/P Battery Holder J-Box 910-369 Low Voltage Junction Box 911-181 Battery Holder Wire Harness City Series CP50E |...

  • Page 46: Proflame Wall Mounting Transmitter

    - Fix the adapter on the wall using the mounting hardware supplied with the remote control. - Insert the remote control onto the adapter as shown in Fig. B. Fig. A: Detach the adapter from the body Fig. B: Adapter and remote control | City Series CP50E...

  • Page 47: Lp Conversion Instructions

    . perforated air diffuser on the right side of the burner. IFC cover Trim cover Burner Surround Trim cover Burner Surround CV60E shown Perforated Air 920-179 10.31.19 Diffuser City Series CBV0E | 59 10.03.23 920-708a City Series CP50E |...

  • Page 48: City Series

    2.9" WC (0.72 kpa) Orifice Size #52 DMS Maximum Input 33,000 Btu/h (9.67 kW) Minimum Input 17,000 Btu/h (4.98 kW) Altitude 0-4500 ft (0-1372m) Installer Notice: These instructions must be left with the appliance 920-708a 10.03.23 | City Series CP50E...

  • Page 49: Ng System Data

    Orifice Size #52 DMS Maximum Input 33,000 Btu/h • If you have an incorrect flame pattern, contact (9.66 kW) your Regency® dealer for further instructions. Minimum Input 17,000 Btu/h (4.98 KW) Incorrect flame pattern will have small, probably High Elevation yellow flames, not coming into proper contact with the rear burner or flame sensor.

  • Page 50: Exterior Vent Termination Locations (Non Power Vent)

    * Clearance in accordance with local installation codes and the requirements of the gas supplier a 3 feet (91cm) within a height of 15 feet (4.5m) above the meter / regulator assembly b 3 feet (91cm) above - if within 10 feet (3m) horizontally | City Series CP50E...

  • Page 51: 5" X 8" (127 Mm X 203 Mm) Rigid Pipe Cross Reference Chart (Non Power Vent)

    5" X 8" RIGID PIPE CROSS REFERENCE CHART Components from different Manufacturers may not be mixed. Not all rigid pipe components are available directly from Regency. Note: Olympia Ventis DV venting is only approved for certain models. See list of approved models in cross-reference chart.
  • Page 52 TM-5ST14 Snorkel Termination 36" 58DVA-SNK36* TM-5ST36 Restrictor Disk Colinear Flex Connectors * Not available from Regency 946-604/P Simpson Direct Vent or Astro Cap -Vent Guard (Optional) 946-623/P AstroCap XL Horizontal Cap 770-994 Rigid Pipe Adaptor (Must use with all rigid piping)

  • Page 53: Vent Restrictor Position (Non Power Vent)

    1-1/2" (38 mm) Factory Set Set 1 3-1/2" (89 mm) Set 5 3/4" (19 mm) Set 2 3-1/8" (79 mm) Set 3 2-3/8" (60 mm) Cross section showing the ceiling of the firebox from the inside City Series CP50E |...

  • Page 54: Venting Introduction (Non Power Vent)

    Venting Introduction (Non Power Vent) The CP50E uses the "balanced flue" technology co-axial system. The inner liner vents products of combustion to the outside while the outer liner draws outside combustion air into the combustion chamber, thereby eliminating the need to use heated room air for combustion and losing warm room air up the chimney.

  • Page 55: Horizontal Terminations - Flex Vent 5" X 8" (127 Mm X 203 Mm)

    Horizontal Terminations - Flex Vent 5" x 8" (127 mm x 203 mm) (Non Power Vent) These venting systems, in combination with the CP50E Direct Vent Gas Fireplace, are tested and listed as a direct vent heater system by Intertek. The location of the termination cap must conform to the requirements in the vent terminal locations diagram in the "Exterior Vent Termination Locations"...

  • Page 56: Horizontal Terminations - Rigid Pipe 5" X 8" (127 Mm X 203 Mm)

    Products Ameri Vent Direct Vent, Security Secure Vent , ICC Excel, Selkirk Direct-Temp. AstroCap is a proprietary trademark of FPI Fireplace ® Products International Ltd. Dura-Vent® and Direct Vent are registered and/or proprietary trademarks of Simpson Dura-Vent Co. Inc. | City Series CP50E...

  • Page 57: Horizontal Terminations - 5" X 8" (127 Mm X 203 Mm) Rigid Or Flex Pipe

    10' (3 m) 7' (2.1 m) elbows. 6' (1.8 m) 5' (1.5 m) 11' (3.4 m) 8' (2.4 m) 7' (2.1 m) 6'(1.8 m) 12' (3.7 m) 9' (2.7 m) Restrictor Set 0 - Factory Setting City Series CP50E |...

  • Page 58: Venting Arrangement For Vertical Terminations - 5" X 8" (127 Mm X 203 Mm) Rigid And Flex Pipe

    Set 0 through to Set 5, if required. For vertical terminations, the Regency Direct Vent Flex System may be used for installations with a maximum vent length of up to 40 feet including offsets. If longer runs are required, Vent restrictor on rigid pipe must be used.

  • Page 59: Vertical Terminations - 5" X 8" (127 Mm X 203 Mm) Rigid Pipe

    Products Ameri Vent Direct Vent, Security Secure Vent , ICC Excel, Selkirk Direct-Temp. AstroCap is a proprietary trademark of FPI Fireplace ® Products International Ltd. Dura-Vent® and Direct Vent are registered and/or proprietary trademarks of Simpson Dura-Vent Co. Inc. City Series CP50E |...

  • Page 60: Vertical Terminations - 5" X 8" - Rigid Or Flex Pipe

    Must use optional rigid pipe adaptor (part# 770-994) when using rigid pipe vent systems. The Regency Direct Vent Flex System may be used for installations with a maximum vent length of up to 40 feet including offsets. Vertical Venting with Three (3) 90...

  • Page 61: Vertical Terminations - Vertical Flex Vent Kit (Part #946-772)

    4 screws/nails. If more than one is required, these can be purchased separately. The ceiling firestop/firestop spacer may be cut down to size if this shield is too high for the application. 11" Ceiling firestop Diagram 2 920-385 Page 1 04.29.21 City Series CP50E |...
  • Page 62 Note: Any closets or storage spaces which the vent passes through must be enclosed. Diagram 3a Diagram 3a Diagram 3a 920-328 09.18.20 City Series ACB60E | 61 920-328 09.18.20 City Series ACB60E | 61 | City Series CP50E 920-385 Page 2 04.29.21...

  • Page 63: Vertical Flue Extension Kit (Part # 946-769)

    (0.91 m) to avoid excessive stress and sagging of the vent pipe. Wall straps are provided (3 in total) for this purpose. All round/plumbers strapping may also be used if further supports are required. City Series CP50E | 919-696 06.11.18...

  • Page 64: Ceiling Firestop / Firestop Spacer (Part # 946-770)

    Firestops can be purchased separately if more than one is required. Diagram 1a The ceiling firestop/firestop spacer may be cut Diagram 1a Ceiling firestop down to size if it is too high for the application. Diagram 1a | City Series CP50E 920-328 920-337 10.05.20 10.05.20 920-338 10.05.20...

  • Page 65: Non-Power Vent Wiring Diagram

    911-311/PV PFII IFC Board 911-189 SIT Gas Valve LP Lamp Green to Ground 946-799 SIT WIFI Dongle Kit User Interface 911-344 Power Harness w/Aux Comfort Fan Connector Split Flow 911-253- Main Line Motor 911-272 Variable Lights City Series CP50E |...

  • Page 66: Wiring The Unit (Both Non Power Vent/Power Vent)

    NOTE: The receptacle and receptacle cover may be located in the manual pack and may need to be installed. 6. Feed any excess wiring into the wall and reinstall the plate onto the wall of the unit. 7. Reinstall electrical box and plate onto screws. 8. Tighten screws to secure. | City Series CP50E...
  • Page 67 * Clearance in accordance with local installation codes and the requirements of the gas supplier 3 feet (91cm) within a height of 15 feet (4.5m) above the meter / regulator assembly 3 feet (91cm) above - if within 10 feet (3m) horizontally City Series CP50E |...

  • Page 68: Exterior Vent Termination Locations (Power Vent)

    Vertical Terminations (Inline): Only Simpson Duravent rigid pipe is approved for use. Must use the 46DVA-VCH vertical high wind cap as this is the only approved cap. Components from different Manufacturers may not be mixed. Not all rigid pipe components are available directly from Regency.

  • Page 69: 4"X 6-5/8" Rigid Pipe Cross Reference Chart (Power Vent)

    20-3/4” (527mm) Metal-Fab Sure Seal: www.mtlfab.com 24” (610mm) 20-5/8” (524mm) 29-1/8” (740mm) Security Secure Vent: www.securitychimneys.com 36” (914mm) 29” (737mm) 37-1/2” (953mm) Industrial Chimney Company: www.icc-rsf.com 48” (1219mm) 37-7/16” (951mm) 45-15/16” (1167mm) Olympia Ventic DV: www.olympiachimney.com City Series CP50E |...

  • Page 70: Introduction (Power Vent)

    Part # of the Power Vent System manual is 920-544. Minimum Vent Clearances to Combustibles Horizontal Top 3" (76mm) Horizontal Side 2 " (51mm) Horizontal Bottom 2" (51mm) Power Vent System Vertical Vent 2" (51mm) Manual | City Series CP50E...

  • Page 71: Horizontal Terminations - Inline Horizontal Vent Chart

    Vent Restrictor Position Vent Restrictor Position No vent restrictor required. No vent restrictor required. Set 0 Set 0 Fully open Fully open Factory Set Factory Set 3 1 8 " City Series CP50E | 920-210b 09.22.20 3 1 8 "...

  • Page 72: Horizontal Terminations - End Of Line Horizontal Vent Chart

    • • Minimum 4' (1.2 m) from the unit prior to terminating. Minimum 4' (1.2 m) from the unit prior to terminating. Vent Restrictor Position No vent restrictor required. Set 0 Fully open Factory Set | City Series CP50E 3 1 8 "...

  • Page 73: Venting Arrangements For Vertical Terminations

    THIS DRAWING IS THE PROPERTY OF FPI LTD., IT MAY NOT BE COPIED IN WHOLE t to inline PV Min. 2' (0,61 m) from inline PV to termination cap Min. 4' (1.22 m) from top of unit to inline PV City Series CP50E | 920-210b 09.22.20...

  • Page 74: Wiring Diagram - Power Vent Application

    Electrical Shielding 911-253-ASM Main Power 911-193 Connector w/ 946-535/666- Power Vent Copper Line to Jumper Ground 911-188 Gas Valve NG 911-305/P Fan Motor 911-314 PV Switch 911-189 Gas Valve LP (Inline) Load 946-799 SIT WIFI Dongle Kit | City Series CP50E...

  • Page 75: Non Power Vent/Power Vent Switch

    To access the switch, remove the screw and pull the cover off as shown below. 1. Locate the power vent switch cover. 2. Remove the screw and pull the cover off. 3. Flip the switch to power vent mode (O) as shown. City Series CP50E |...

  • Page 76: Installation - Panels, Barriers, Faceplate

    Handle glass with supplied vacuum clamps Note--the following installation diagrams do not include the vacuum clamps but it is strongly recommended to use Lower clamps (x4) in open position clamps at all times when handling the firebox glass. | City Series CP50E...
  • Page 77 7. To install glass--reverse steps. IMPORTANT: Remove glass panel completely when installing or removing panels, logs, media, etc. to avoid causing any damage to the glass. City Series CP50E |...

  • Page 78: End Inner Firebox Glass Panel Installation/Removal

    1. Remove outer barrier safety glass. Install the transportation support brackets. These would have been placed underneath the appliance when installed. See transportation support removal in this manual. 4. Locate the two brackets holding the top end clamps and remove the screws to remove the brackets. | City Series CP50E...
  • Page 79 5. Attach the suction cup to the End glass panel. 6. Open the bottom and top clamps holding the glass panel. 7. Remove the glass panel. 8. Reverse process to reinstall End firebox glass panel. City Series CP50E |...

  • Page 80: Glass Barrier Installation & Barrier Glass Adjustment

    4. Slide the corner protectors onto the bottom corners of the glass. SIDE A SIDE B BARRIER GLASS BARRIER GLASS BARRIER GLASS BARRIER GLASS 5. Install the End barrier glass first. | City Series CP50E...
  • Page 81 Counter clockwise = angles barrier in towards the unit. Counter clockwise = angles barrier in towards the unit. 8. Install Side A and Side B barrier glass. Slide the screwdriver straight up at the two indicator slots. City Series CP50E |...
  • Page 82 UNITS IN INCHES ANGULAR = 1 E.C.N.: SIGN: DATE: THIS DRAWING IS THE PROPERTY OF FPI LTD., IT MAY NOT BE COPIED IN WHOLE OR IN PART, OR DISCLOSED TO A THIRD PARTY WITHOUT OUR PRIOR WRITTE | City Series CP50E...

  • Page 83: Inner Black Steel/Enamel Panel Installation

    #7 x 1 13-13/32" (340 mm) x 4-3/4" (121 mm) 5. Clean panels with a cloth. Add the desired media or logs before installing the inner firebox glass. See this manual for instructions on how to install the firebox glass. City Series CP50E |...
  • Page 84 DETAIL F SCALE 1 : 8 9. Clean the outer panels with a cloth before installing the safety outer barrier glass. To install the safety glass, see this manual for instructions. | City Series CP50E 920-802 06.28.24...

  • Page 85: Inner Black Glass Panel Installation

    5. S lide the side glass panel #4 into the bottom side bracket and secure the side glass by mounting the top bracket and tightening the 2 screws. Item Description 2-3/16" (56 mm) x 16-1/4" (412 mm) steel panel 2-3/16" (56 mm) x 16-1/4" (412 mm) glass panel 2-1/4" (57 mm) x 6-3/4" (171 mm) steel panel 11-1/16" (281 mm) x 17-11/16" (449 mm) glass panel 4-5/16" (110 mm) x 16-1/4" (412 mm) combined panel 5" (127 mm) x 17-7/8" (454 mm) combined panel 4-5/16" (110 mm) x 21-13/16" (554 mm) com- bined panel 13-13/32" (340 mm) x 4-3/4" (121 mm) combined panel 3. Drop the 6 #1 inner steel panels into the firebox as shown below. 6. C lean panels with a cloth. Add desired media or logs before installing the inner firebox glass. See this manual for instructions on how to install firebox glass. City Series CP50E | 920-803 07.08.24...
  • Page 86 CP50E installation-panels, barriers, faceplates 7. Install 2 #5 panels, 1 #7 panel and 1 #8 panel as shown below. 9. Slide the side outer #6 glass panels between the wall and the barrier stopper bracket. If the unit does not have a barrier stopper, stick the side outer panels to the magnets. NOTE: One side shown only. Repeat steps for other side. 8. Optional: install the glass barrier stopper. If the unit doesn't have a glass stopper, proceed to the next step. 10. C lean the outer panels with a cloth before installing the safety outer barrier glass. To install the safety glass, see this manual for instructions. DETAIL F SCALE 1 : 2 | City Series CP50E 920-803 07.08.24...

  • Page 87: Installation-Media

    * Media not supplied with unit - must be purchased separately. Media should only cover up to a maximum of 50% of the burner surround. 3/4" Adriron Black Embers + Fireglass Black Coal Crushed Glass + Fireglass Embers Lava + Fireglass City Series CP50E |...
  • Page 88 Firebeads + Fireglass Crushed Glass Iceburg Chips + Fireglass Ceramic Spa Stones + Fireglass River Pebbles and Fireglass Volcanic, Ivory/Tan Basalt, + Natural Stones + Fireglass | City Series CP50E...

  • Page 89: Fire Balls Media (18 Pcs) Installation (Part #946-793)

    2. Install the 3.5 lb box of black charcoal glass and 1 lb of Andiron embers around the burner. Make sure the burner surround is only 50% covered. 3. Place the various sized fire balls as shown. Ensure the fire balls do not cover any of the buner ports. Final Installation City Series CP50E | 920-778 04.03.24...

  • Page 90: Optional Log Set Installation

    Note: These instructions apply to all 3 log sets (driftwood,Birch,Split Oak). Installation instructions note the driftwood log set but same steps will be taken when installing either the Birch or Split oak. Driftwood Log Set Birch Log Set Split Oak Log Set | City Series CP50E 04.03.24 920-713...
  • Page 91 PV SWITCH IFC BOARD 5. Install black fireglass (1.5 lb) and glowing wool on the burner as shown below. 6. Locate the hole on the burner surround, on the left side of the pilot. Insert the pin underneath Log 1 into the hole on the burner surround. Pilot City Series CP50E | 920-713 04.03.24...
  • Page 92 8. Locate the hole on the right side of the pilot. Pilot 9. Insert the pin of Log 2 into the hole. Lay the log on the firebox, then measure the edge of the log to the side as shown below. 1/2" 10. Connect Log 3 to the pin on Log 1. Rest Log 3 on the landing on Log 1. Landing | City Series CP50E 04.03.24 920-713...
  • Page 93 13. Place Log 6 on top of Log 3, ensuring the pin on Log 3 is aligned with the hole on Log 6, and that Log 6 rests on the landing on Log 3. 920-713 04.03.24 City Series CP50E |...
  • Page 94 14. Place Log 7 on top of Log 4, ensuring the pin on Log 4 is aligned with the hole on Log 7. Slide the log until touching the back panel 15. Install Log 11 on the end Log 7, as shown below. 16. Install Log 8 between Log 3 and Log 4, as shown below. 920-713 04.03.24 | City Series CP50E...

  • Page 95: Final Placement

    19. Install the 3.5 lb box of black charcoal glass (optional) or 1lb box of Andriron embers (optional) around the burner. Make sure the burner surround is only 50% covered. Correct Coal Placement Final Placement City Series CP50E | 920-713 04.03.24...

  • Page 96: Wifi Dongle Installation (Optional)

    8. Reinstall the outer panels and safety glass – see manual. 9. Gas supply can be turned back on & 120 Volt Ac power may be reconnected. 10. See QR code below or on box from this WIFI kit to install the Proflame app. | City Series CP50E 06.27.22 920-550...

  • Page 97: Maintenance

    8. Verify operation after servicing. If your glass breaks, purchase a replacement from If a log needs replacing, you must use the proper an authorized Regency dealer. Replacement glass replacement log. The position of these logs must be Flame Pattern is shipped already installed into the door frame.

  • Page 98: Aeration Adjustment

    Pushing lever in opens the air shutter. • Pulling the lever outward closes the air shutter. aeration handle The aeration handle is located near the right side of the gas valve access door, attached by a magnet. | City Series CP50E...

  • Page 99: Bulb Replacement

    • Do not handle bulb with bare hands. Use packaging or a tissue to hold new bulb when replacing. Regency part# 911-208 Oven lamp assembly G9 120V/25W Regency part# 911-072 Replacement bulb G9 120 Volt/25 watt Light gasket Light glass...

  • Page 100: Valve Replacement

    Burner screw locations Burner screw locations 8. Remove 13 screws in locations shown below. 11. Reverse Steps 10-1 to complete. 11. Reverse Steps 10-1 to complete. 11. Reverse steps 10-1 to complete. DETAIL A SCALE 1 : 4 | City Series CP50E...

  • Page 101: Gas Maintenance - Recommended Annual Routine

    • Burner orifice • Burner media (change as needed) • Thermocouple (millivolt models) • Air shutter setting • Thermopile (millivolt models) • Wiring Gas Leak Tests • Check main gas line connection to valve • Check shut off valve connections • Check connection at gas valve outlet • Check connection at main burner orifice • Check pilot fuel line at valve and at pilot assembly 920-324 09.14.20 City Series CP50E |...

  • Page 102: Parts List

    Main Assembly 4, 5, 6, 8, 9, 10, 11 | City Series CP50E...
  • Page 103 Valve Assembly Gasket 905-001 Phillip Offset Screwdriver (Removal Of Finishing Lip) 656-039 Gasket Orifice Mount 918-835 Decal Logo Regency / Flame Sit Remote 904-165 Fitting 3/8 Male Flarex Mpt Strt Adaptor 918-876 Decal Remote Quick Reference GTMF 904-606 Fitting 90 Street Elbow Extruded...

  • Page 104: Accessories

    Description 656-550 Regency Logo Assembly (Each) 482-036 Gasket Bottom Pressure Relief Right 948-223 Logo Plate Plastic Regency/Flame Silver 482-081 Gasket Bottom Pressure Relief Left 904-790 Magnet Round 1/2 inch x 1/8 inch 904-970 Magnet Cup 1/2 inch x 5/8 inch...

  • Page 105: Upper Glass Clamps (Side A Or B)

    Upper Glass Clamps (Side A or B) Item Part # Description 666-038 Upper/Lower Glass Clamps Right 666-039 Upper/Lower Glass Clamps Left Lower Glass Clamps (Side A or B) Item Part Description 666-038 Upper/Lower Glass Clamps Right 666-039 Upper/Lower Glass Clamps Left City Series CP50E |...

  • Page 106: Power Vent-End Of Line (Part # 946-535)

    UNITS IN INCHES ANGULAR = E.C.N.: DATE: SIGN: THIS DRAWING IS THE PROPERTY OF FPI LTD., IT MAY NOT BE COPIED IN WHOLE OR IN PART, OR DISCLOSED TO A THIRD PARTY WITHOUT OUR PRIOR WRITTEN CONSENT. | City Series CP50E...

  • Page 107: Power Vent - Inline (Part # 666-945)

    UNITS IN INCHES ANGULAR = 1 E.C.N.: DATE: SIGN: THIS DRAWING IS THE PROPERTY OF FPI LTD., IT MAY NOT BE COPIED IN WHOLE OR IN PART, OR DISCLOSED TO A THIRD PARTY WITHOUT OUR PRIOR WRITTEN CONSENT. City Series CP50E |...

  • Page 108: Warranty

    *This warranty does not cover dealer travel costs, mileage, fuel, tolls for diagnostic or service work. All labor rates paid to authorized dealers are subsidized, pre-determined rates. Dealers may charge you for travel and additional time beyond their subsidy. | City Series CP50E...
  • Page 109 A copy of the receipt or bill of sale will be necessary to validate the purchase price. City Series CP50E |...

  • Page 110: Limitations Of Liability

    Customers located outside the US should consult their local, provincial or national legal codes for additional terms, which may apply to this warranty. | City Series CP50E...
  • Page 111 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com/Customer-Care/Warranty-Registration.aspx...
  • Page 112 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
  • Page 113 City Series CP50E |...

  • Page 114: Recycling

    By recycling your used appliances, you divert waste from your local landfills and help the environment. You also reduce the need for raw materials to manufacture new products. Contact your local municipality for appliance recycling services, local recycling programs, or appliance removal services to ensure your Regency appliance components, and packaging are properly recycled.
  • Page 116 Dealer Name & Address: ________________________________________________ ____________________________________________________________________ Installer: ____________________________________________________________ Phone #: ____________________________________________________________ Date Installed: ________________________________________________________ Serial #:_____________________________________________________________ Printed in Canada Regency and City Series are trademarks of FPI Fireplace Products International Ltd. © Copyright 2024, FPI Fireplace Products International Ltd. All rights reserved.

This manual is also suitable for:

City seriesCp50e-ngCp50e-lp
