Horizontal Terminations
The diagrams below shows examples of horizontal termination arrangements using one, two, or three 90
1. A maximum of three 90
o
2. Minimum distance between elbows is 1 ft. (305mm).
• Maintain clearances to combustibles as listed in the "Clearances" section.
• Horizontal vent must be supported every 3 feet.
• Firestops are required at each floor level and whenever passing through a wall.
• Must use optional rigid pipe adaptor (Part# 510-994) when using rigid pipe vent systems.
• A vent guard should be used whenever the termination is lower than the specified minimum or as per local codes.
• Flex system can only be used up to 10 feet - otherwise rigid venting must be used.
Horizontal Venting with Two (2) 90
One 90 elbow = Two 45
o
Option V H + H1
A) 1' Min. 2' Max.
B) 2' Min. 4' Max.
C) 3' Min. 5' Max.
D) 4' Min. 6' Max.
E) 5' Min. 7' Max.
F) 6' Min. 8' Max.
Restrictor Set 0 - Factory Setting
- Rigid/Flex Pipe 4" x 6-5/8"
elbows are permitted.
Elbows
o
elbows.
o
W i t h t h e s e o p t i o n s ,
maximum total pipe length
is 30 feet with minimum
of 6 feet total vertical
and maximum 8 feet total
horizontal.
Please note minimum
1 foot between 90
elbows is required.
Horizontal Venting with Three (3) 90
Option
A) 1' Min.
B) 1' Min.
C) 2' Min.
D) 3' Min.
E) 4' Min.
o
F) 5' Min.
G) 6' Min.
H) 7' Min.
Restrictor Set 0 - Factory Setting
elbows (two 45 elbows equal one 90
o o
One 90 elbow = Two 45
o
V H V + V1 H + H1
1' Max. 2' Min. 2' Max.
2' Max. 3' Min. 3' Max.
2' Max. 5' Min. 4' Max.
2' Max. 7' Min. 5' Max.
3 Max. 9' Min. 6' Max.
4' Max. 10' Min. 7' Max.
5' Max. 11' Min. 8' Max.
6' Max. 12' Min. 9' Max.
City Series CV40E-12 |
installation
elbow)
o
Elbows
o
elbows.
o
With these options,
max. total pipe
length is 30 feet with
min. of 12 feet total
vertical and max. 9
feet total horizontal.
Please note min.
1 foot between
90 elbows is
o
required.
