installation
CITY SERIES
Clean Trim Faceplate Installation
CLEAN TRIM FACEPLATE INSTALLATION
1. Frame in fireplace and install finishing material. (Clean Trim Faceplate can
4. Hand bend attachment tabs so they bend past the magnets to the metal
accommodate finishing materials for 1/2 inch to 1 1/8".)
wall inside the opening.
5. Affix Clean Trim Faceplate with self-tapping screws that are included in
2. Prior to installing outer liner panels and barrier glass remove finishing trim
the box.
plates from right and left sides.
3. Insert Clean Trim Faceplate into fireplace opening.
1
04.17.20
920-259
City Series CV40E-12 |
65
