Dimensions - Regency CV40E-12 Owners & Installation Manual

CV40E Dimensions
Ø 6 3 4 "
171mm
Ø 4"
102mm
40 "
1016mm
46 1 4 "
"
1175mm
43"
1091mm
Optional Clean Trim Faceplate Dimensions
Note: Electrical connection on left hand side of the appliance.
A metal receptacle box is supplied/installed with the appliance to make all 120 volt electrical connections.
Note: Height Dimension may vary depending on the height of the leveling legs.
Dimensions will appear as (inches)" / (metric)mm throughout this manual. The inches are rounded to the
nearest 1/16" when converted, when greater accuracy is required, use the metric dimensions.
Note: These units are non-load bearing.
ALL PICTURES / DIAGRAMS SHOWN THROUGHOUT THIS MANUAL ARE FOR ILLUSTRATION PURPOSES ONLY.
ACTUAL PRODUCT MAY VARY DUE TO PRODUCT ENHANCEMENTS.
21 7 8 "
556mm
1057mm
3RD ANGLE TOLERANCES UNLESS
PROJECTION OTHERWISE STATED

DIMENSIONS

0.000 = 0.01 CRITICAL
0.000 = SPECIFIED TOLERANCE
DO NOT SCALE
0.000 = 0.031
DRAWING
0.000 REF = REFERENCE ONLY
UNITS IN INCHES ANGULAR = 1
THIS DRAWING IS THE PROPERTY OF FPI LTD., IT MAY NOT BE COPIED IN WHOLE OR IN PART, OR DISCLOSED TO A THIRD PARTY WITHOUT OUR PRIOR WRITTEN CONSENT.
Gas Line Entry
18 11 16 "
475mm
17 11 16 "
449mm
5
41 "
8
3
"
4
19mm
FIREPLACE PRODUCTS
INTERNATIONAL
1:8
SCALE:
SFORSYTHE
DWN:
E.C.N.:
2'' (51mm)
13''
(330mm)
3-1/2''
(89mm)
5
16 "
16
414mm
10 GA COLD ROLL
MAT'L :
LASERCUT
PROCESS :
CV40 FRONT FRAME
PART :
1/17/2020
PART NO:
DATE:
656-451
SIGN: DATE:
City Series CV40E-12 |
dimensions
REV:
A
7
