CP60E DIRECT VENT
STYLE
Pier
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
Certified to/Certifié pour:
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
920-470c
City Series ®
MODEL
CP60E-NG / CP60E-LP
CSA 2.17-2017
ANSI Z21.88-2019
CSA 2.33-2019
Installer: Please complete the details on the back cover and leave this
manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Owners &
Installation Manual
www.regency-fire.com
06.29.23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the City CP60E and is the answer not in the manual?

Questions and answers

Related Manuals for Regency City CP60E

Summary of Contents for Regency City CP60E

  • Page 1 City Series ® Owners & CP60E DIRECT VENT Installation Manual STYLE MODEL www.regency-fire.com Pier CP60E-NG / CP60E-LP WARNING FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
  • Page 2 The CP60E City Series have been approved by Intertek for both safety and efficiency. As it also bears our own mark, it promises to provide you with economy, comfort and security for many trouble-free years to follow. Please Front take a moment now to acquaint yourself with these instructions and the many features of your Regency Fireplace. ®...
  • Page 3 MANUFACTURED MOBILE HOME REQUIREMENTS INFORMATION FOR MOBILE/MANUFACTURED HOMES AFTER FIRST SALE This Regency product was tested and listed by Intertek as a Direct Vent Wall Furnace to the following standards: Vented Gas Fireplace ® Heaters ANSI Z21.88-2019 • CSA 2.33-2019 and Gas-fired Appliances for Use at High Altitudes CSA 2.17-2017.
  • Page 4 WARNING CARBON MONOXIDE POISONING HAZARD Failure to follow the steps outlined below for each appliance connected to the venting system being placed into operation could result in carbon monoxide poisoning or death. The following steps shall be followed for each appliance connected to the venting system being placed into operation, while all other appliances connected to the venting system are not in operation: 1.

  • Page 5: Table Of Contents

    table of contents Owner's information Horizontal Terminations - Rigid Pipe 5" x 8" (127 mm x 203 mm) ... 55 Horizontal Venting with Two 90 Elbows ........56 Copy of Safety Decal ..............6 Horizontal Venting with Three 90 Elbows ........56 Decal Location ................

  • Page 6: Copy Of Safety Decal

    It is visible when the outer front panel is removed. • Regency® units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one.
  • Page 7 installer's information MA Code - CO Detector (for the State of Massachusetts only) 5.08: Modifications to NFPA-54, Chapter 10 (2) Revise 10.8.3 by adding the following additional requirements: (a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied:...

  • Page 8: Important Message

    owner's information Important Message WE RECOMMEND REMOVING THE CHILDREN AND ADULTS SHOULD BE GLASS WITH THE GLASS VACUUM ALERTED TO THE HAZARDS OF HIGH SAVE THESE INSTRUCTIONS HOLDERS SUPPLIED BY THE MANU- SURFACE TEMPERATURES, ESPE- FACTURER. REST THE GLASS IN A CIALLY ON THE FIREPLACE GLASS, City Line Direct Vent Fireplaces must be installed SAFE PLACE TO PREVENT DAMAGE TO...

  • Page 9: First Fire

    owner's information First Fire Normal Operating Sounds Of Gas Appliances To ensure that the paint is properly cured, it is recommended that you burn a fire in your fireplace It is possible that you will hear some sounds from for at least four (4) hours the first time. During the your gas appliance.

  • Page 10: Lighting Procedure

    owner's information Lighting Procedure • The remote control system supplied has several options • The first try for ignition will last approximately 60 seconds. If there is no flame ignition (rectification), the board will stop sparking for ap- for starting/operating the appliance using the battery proximately 35 seconds.

  • Page 11: Copy Of The Lighting Plate Instructions

    owner's information Copy of the Lighting Plate Instructions FOR YOUR SAFETY READ BEFORE LIGHTING POUR VOTRE SÉCURITÉ – À LIRE AVANT LA MISE EN MARCHE WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life.

  • Page 12: Proflame Ii Remote Control Operating Instructions

    owner's information Proflame II Remote Control Operating Instructions • The transmitter and IFC are radio frequency devices. • The Proflame Transmitter 2 is an integrated part of the Proflame 2 System, which consists of these elements: » Proflame 2 Transmitter, in conjunction with »...
  • Page 13 owner's information Temperature Indication Display Remote-Flame Control With the system off, press the THERMOSTAT key and the MODE key at The Proflame has six (6) flame levels. With the system on and flame level the same time. Look on the transmitter's LCD screen for a C or F to the at maximum, the DOWN ARROW key will reduce the flame height by one right of the room temperature display (figures 4 &...
  • Page 14 owner's information Smart Thermostat (Transmitter Operation) Remote Dimmer Control (Light)** The auxiliary function controls the AUX power outlet by the dimmable The smart thermostat function adjusts the flame height based on the light control. To activate this function, use the MODE key (fig. 1) to scroll difference between the set point and the actual room temperatures.
  • Page 15 owner's information Continuous Pilot/Intermittent Pilot (CPI/IPI) 4. The screen will show either "Clr" or "Set". 5. "Clr" will remove a mode—use the up or down arrow while holding selection the ON/OFF and MODE keys (mode icon will disappear once removed). Power vent models do not have a continuous pilot (CPI) option.

  • Page 16: Proflame Ii Battery Holder Battery Replacement

    owner's information Proflame II Battery Holder Battery Replacement & Battery Back Up if 120 Volt Power is lost IMPORTANT Battery Holder Battery Replacement & Battery Back up if 120 volt power is lost Non-Power Vent Model: Install the 4 AA batteries during power outages to run the main burner. However, the lights will not operate witihin home Power Vent Model: This appliance will not operate if 120 volt power is lost within the home.

  • Page 17: Wifi Dongle Installation (Optional)

    CITY SERIES 60 owner's information WIFI Dongle Installation (Optional) WIFI Dongle Installation Instructions 1. Remove the outer panels and safety glass – see manual. 5. Locate the dongle holder on the right side of the IFC. 2. Loosen the 2 screws on the IFC cover and remove the cover to access the IFC.

  • Page 18: Maintenance Instructions

    Conduct an inspection of the venting system purchase your replacement from an authorized semiannually. Recommended inspection areas are Regency dealer only. Replacement glass is shipped listed below. already installed into the door frame. Reinstall as per the instructions in the "Glass Installation"...

  • Page 19: Installer's Information

    installer's information Dimensions Side B Side B Side B Side A Side A Side A Side A Side A Side B Side A Side B Side A Side B 3RD ANGLE TOLERANCES UNLESS FIREPLACE PRODUCTS MAT'L : Item Description PROJECTION Item Description OTHERWISE STATED Measurement...

  • Page 20: Gas Connection - Bottom Of Unit

    installer's information Gas Connection - Bottom of Unit Side B Side B Side A Side A 9-13/16" (249 mm) 4-1/4" (108 mm) 3-1/6" (78 mm) 18" (457 mm) 28-1/8" (715 mm) 11 knockouts total, each 2" (51 mm) x 18" (457 mm) 12-3/4"...

  • Page 21: General Safety Information

    installer's information General Safety Information Installation Checklist 10. Plug the three-prong plug for the lights into the receptacle. The three-prong plug is located near the gas valve on the appliance. 1. Choose a location for your appliance. Refer to 1. The appliance installation must conform with the following sections: local codes, or in the absence of local codes, 11.

  • Page 22: Locating Your Gas Fireplace

    installer's information Locating Your Gas Fireplace 1. When selecting a location for your fireplace, ensure that the clearances are met as outlined in the "Clearances" section. 2. Provide adequate clearances for servicing. 3. The appliance must be installed on a flat, solid, continuous surface (e.g., wood, metal, concrete).

  • Page 23: Unit Assembly Prior To Installation

    installer's information Unit Assembly Prior to Installation Warning: Do not remove two transportation supports until framing and finishing are done. Before you start - removing the unit from the pallet Remove the screws securing the unit to the pallet. Due to the CP60E's size and weight (617 pounds/280 kg shipping weight), Unit Assembly Prior to Installation lifting and moving the unit requires 4 people.

  • Page 24: Transportation Support Removal

    installation - general Transportation Support Removal 1. Place the unit in its final position where it will be installed and finished. 2. Remove the transportation supports by removing the 8 screws through the access holes on the top and bottom faces at the end of the unit. Screw access behind the bottom face 3.

  • Page 25: Access Panel Removal

    installer's information Access Panel Removal The front access panels (x3) may be removed for ease of hooking up gas and electrical prior to finishing. Once complete, ensure that the access panels are reinstalled prior to any finishing. See locations in the diagram to the right. Once the finished material is installed, these access panels are no longer accessible.

  • Page 26: Installation - General

    Framed opening must be between 4” (102 mm) and 4.5” (114 mm) tall, and at least 42.25”(1073 mm) wide to accommodate the chase vent. The top of the chase vent opening must be 3” or less from the top of the chase enclosure.

  • Page 27: Clearances - Flush Installation

    installation - general Clearances - Flush Installation Warning: Fireplace is non-load bearing. Do not transfer the weight of the framing and finishing material to the fireplace. The whole weight of the framing and wall finishing must be supported by wall stud or other means. The clearances listed below are minimum requirements for either side of this Pier fireplace, unless otherwise stated.

  • Page 28: Flush Installation Examples (Ventilation Openings)

    installation - general Flush Installation Examples (Ventilation Openings) • When creating any type of ventilation opening, measures should be taken to prevent objects falling or being thrown into the ventilation opening. Mesh screen, louvers, or other protection should be used. •...
  • Page 29 installation - general 2nd ventilation opening in seperate room OPTION 3 - BOTH SIDES A = 2" (0 - 51 mm) max. B = 120 sq in min. C = 4" (102 mm ) min. 2" (0 - 51 mm) max. D = 10"...
  • Page 30 installation - general Ventilation Opening Ceiling 1-3/4" (44 mm) min. OPTION 5 - REVEAL AT TOP A: 1-3/4" (44 mm) min. Option 5 - Reveal at Top Shown with ventilation opening at the top of enclosure to meet the minimum requirement of 120 sq.

  • Page 31: Clearances - Bench Installation

    installation - general Clearances - Bench Installation Warning: Fireplace is non-load bearing. Do not transfer the weight of the framing and finishing material to the fireplace. The whole weight of the framing and wall finishing must be supported by wall stud or other means. The clearances listed below are minimum requirements for either side of this Pier fireplace, unless otherwise noted.

  • Page 32: Bench Installation Examples (Ventilation Openings)

    installation - general Bench Installation Examples (Ventilation Openings) • When creating any type of ventilation opening, measures should be taken to prevent objects falling or being thrown into it. Mesh screen, louvers, or other protection should be used. • **If the ventilation openings are placed in two rooms (two different pressure zones), the ventilation openings must have equally split air openings to balance airflow.
  • Page 33 installation - general 3 - FRONT/BACK WALL WITH SECOND VENTILATION IN SEPERATE ROOM A = 10" (254 mm) min. B = 2" (51 mm) max. C = 90 sq in front and back D = 1- 1/2" (38 mm) min. 10"...
  • Page 34 installation - general 10" (254 mm) min. OPTION 5 - FRONT 2" (51 mm) min. 180 sq. in min. A = 10" (254 mm) min. B = 2" (51 mm) min. 1-1/2" (38 mm) min. C = 180 sq in D = 1-1/2"...

  • Page 35: Mantel Clearances

    installation - general Mantel Clearances MANTEL CLEARANCES Combustible mantel clearances from top of front facing are shown in the diagram below. 12" (305 mm) maximum 9" (229 mm) 5-1/4" (133 mm) maximum 3RD ANGLE TOLERANCES UNLESS FIREPLACE PRODUCTS MAT'L : 18-1/16"...

  • Page 36: Mantel Leg Clearances

    installation - general Mantel Leg Clearances Combustible mantel leg clearances as per diagram. MANTEL LEG CLEARANCES One side shown. Clearances are the same Mantel Leg 7" (179 mm) on the other side. A = Mantel Leg Allowable mantel leg projection 5"...

  • Page 37: Framing Dimensions

    installation - general Framing Dimensions Warning: The fireplace is non-load bearing. Framing may be constructed of combustible material (i.e. 2 x 4 or 2 x 6) and does not require steel studs. Framing Description CP60E Dimensions For 2" x 4": 45-1/8" (1146 mm) Framing height For 2"...

  • Page 38: Chase Vent Installation (White Front) (Part # 686-991)

    installation - general Chase Vent Installation (White Front) Chase Vent Installation (White Front) (Part # 686-991) Framed Opening must be between 3” and 3.5” tall, and at least 60.25” wide to accomodate the Chase vent. The top of the chase vent opening must be 2” or less from the top of the chase enclosure. •...

  • Page 39: Wall Board/Drywall Installation

    installation - general Wall Board/Drywall Installation Finishing Instructions It is important to follow the framing and finishing instructions in this manual to ensure proper placement of the fireplace in the surrounding materials. Wall board materials 1/2 in. (13 mm) thick are specified in this manual to align with the optional finishing methods offered with this appliance. The CP60E may be finished to the appliance opening with 1/2 inch (13 mm) thick drywall.

  • Page 40: Framing And Finishing Inset Installations

    installation - general Framing and Finishing Inset Installations 1. Frame the enclosure for the unit with framing material. When constructing the framed opening, ensure there is access to install the gas lines and electrical. Also, the wiring harness must be wall mounted using the receptacle provided with the appliance.

  • Page 41: Typical Installations - Flush Tv Install

    installation - general Typical Installations - Flush TV Install Max. 2" (51 mm) to top of enclosure Min. 1-1/2" (38 mm) Chase vent min. open area: 180 sq. in. Bench Install 120 sq. in. Flush Install Max. 5-1/2" (140 mm) (2 x 6 stud) See E for corresponding min.

  • Page 42: Typical Installations - Recessed Tv Install

    installation - general Typical Installations - Recessed TV Install Max. 2" (51 mm) to top of enclosure Min. 1-1/2" (38 mm) Chase vent min. open area: 180 sq. in. (bench Install) 120 sq. in. (fush Install) Max.: 5-1/2" (140 mm) 2 x 6 stud. See E for corresponding min.

  • Page 43: Finishing

    installation - general Finishing CV72 Finishing Flush Install Example - Front edge of side liner panels must not be covered by nishing material or - Loosen screws using supplied O set removal of the Firebox Glass will not be Screwdriver and remove bottom and - Finish up to trim on all 4 sides possible side trim pieces...

  • Page 44: Wall Mount On / Off Switch And Battery Holder Installation

    installation - general Wall Mount On / Off Switch and Battery Holder Installation Required for all installations IMPORTANT: The battery holder must be placed inside the supplied (low voltage) junction type wall box and installed into the wall only. DO NOT INSTALL WITHIN THE CONFINES OF THE FIREPLACE SWITCH MUST BE ACCESSIBLE Battery Holder Installation 1.

  • Page 45: Proflame Wall Mount Transmitter

    installation - general Proflame Wall Mount Transmitter WALL MOUNTING The Proflame remote control/transmitter is supplied with an adapter for wall mounting.Install the controller 59" (1.5m) above the floor level, well away from heat sources, kitchens, doors or windows. Metalllic structures or radio interferences can reduce the operative distance of the device.

  • Page 46: Lp Conversion Instructions

    CITY SERIES 60 installation - general CONVERSION FROM NG TO LP LP Conversion Instructions CP60E/CST60E using SIT 885 NOVA Gas Valve THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION! 6. Disconnect the cable coming from the pressure regulator motor. This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s Cable from motor...
  • Page 47 CITY SERIES 60 installation - general 15. Unscrew the pilot orifice with the Allen key, then replace it with the LPG 12. Loosen 8 screws in the locations shown below (4 at front and 4 at pilot orifice and the pilot cap provided in the kit. rear)—slide the burner to the left, away from the orifice, and lift it out.

  • Page 48: System Data

    Max. Supply Pressure 14"WC (3.45 Kpa) If you have an incorrect flame pattern, contact Min. Supply Pressure 11" WC (2.73 kpa) your Regency® dealer for further instructions. Manifold Pressure 10.5" WC (2.49 kpa) Orifice Size #50 DMS Incorrect flame pattern will have small, probably...

  • Page 49: Exterior Vent Termination Locations

    installation - general Exterior Vent Termination Locations Minimum Clearance Requirements Canada Clearance above grade, veranda, porch, deck, or balcony 12"(30cm) 12"(30cm) Clearance to window or door that may be opened 12"(30cm) 9" (23cm) Clearance to permanently closed window Vertical clearance to ventilated soffit located above the terminal within a horizontal distance of 2 feet (61cm) 29"(74cm) 29"(74cm) from the center line of the terminal (check with the local code)

  • Page 50: 5" X 8" (127 Mm X 203 Mm) Rigid Pipe Cross Reference Chart

    NOTE: Olympia Venis DV venting is only approved for certain models. See list of approved models in cross-reference chart. Components from different Manufacturers may not be mixed. Not all rigid pipe components are available directly from Regency. Note: Olympia Ventis DV venting is only approved for certain models. See list of approved models in cross-reference chart.
  • Page 51 TM-5ST14 Snorkel Termination 36" 58DVA-SNK36* TM-5ST36 Restrictor Disk Colinear Flex Connectors * Not available from Regency 946-604/P Simpson Direct Vent or Astro Cap -Vent Guard (Optional) 946-623/P AstroCap XL Horizontal Cap 770-994 Rigid Pipe Adaptor (Must use with all rigid piping)

  • Page 52: Vent Restrictor Position

    installation Vent Restrictor Position Vent restriction is required for certain venting installations. See the diagrams in the "Installation - Non Power Vent" and "Installation-Power Vent" sections to determine if they are required for your installation. The vent restrictor plate is installed on the appliance at Set 0. To set the vent restriction as indicated in the venting arrangements diagrams, refer to the following instructions;...

  • Page 53: Venting Introduction

    • Must use optional rigid pipe adapter (part# 770-994) when using rigid pipe venting systems. • For horizontal terminations, the Regency direct vent flex system may be used for installations with a maximum continuous vent length of up to 10 feet.

  • Page 54: Horizontal Terminations - Flex Vent 5" X 8" (127Mm X 203Mm)

    S.S. Screws #8 x 1-1/2” Drill Point 10) Vinyl Siding Standoff • Liner sections should be continuous without any joints or seams. • Only flex pipe purchased from Regency® may be used for flex installations. • Horizontal vent must be supported every 3 feet.

  • Page 55: Horizontal Terminations - Rigid Pipe 5" X 8" (127 Mm X 203 Mm)

    installation Horizontal Terminations - Rigid Pipe 5" x 8" (127 mm x 203 mm) Minimum components required for a basic horizontal termination: Horizontal Termination Cap Horizontal Termination Cap Vinyl Siding Rigid Pipe Adaptor (770-994) Standoff (Optional) Wall Thimble Length of pipe to suit wall thickness (see chart) Wall Thimble Wall thickness...

  • Page 56: Elbows

    installation Horizontal Terminations - 5" X 8" (127 mm x 203 mm) Rigid or Flex Pipe The diagrams below show examples of horizontal termination arrangements using one, two, or three 90 elbows (two 45 elbows equal one 90 elbow). 1. A maximum of three 90 elbows are permitted.

  • Page 57: Venting Arrangement For Vertical Terminations - 5" X 8" (127 Mm X 203 Mm) Rigid And Flex Pipe

    Set 0 through to Set 5, if required. For vertical terminations, the Regency Direct Vent Flex System may be used for installations with a maximum vent length of up to 40 feet including offsets. If longer runs are required, rigid pipe must be used.

  • Page 58: Vertical Terminations - 5" X 8" (127 Mm X 203 Mm) Rigid Pipe

    installation Vertical Terminations - 5" x 8" (127 mm x 203 mm) Rigid Pipe The minimum components required for a basic vertical termination are: Vertical Termination Cap Rigid Pipe Adaptor (770-994) Ceiling Firestop Vertical Terminal Flashing Storm Collar Length of pipes to suit wall thickness & vent run (see chart) Storm Collar Galvanized pipe is desirable above the roofline due to its higher corrosion...

  • Page 59: Vertical Terminations - 5" X 8" - Rigid Or Flex Pipe

    Lengths do not include elbow indicated Restrictor Set 0 - Factory Setting • For horizontal terminations, the Regency Direct Vent Flex System may be used for installations with a maximum continuous vent length of 10 feet (3 m). If longer runs are required, rigid pipe must be used.

  • Page 60: Vertical Terminations - Vertical Flex Vent Kit (Part #946-772)

    Termination Cap installation Storm Collar Vertical Termination Flashing 5" (127 mm) x 8" (203 mm) Venting - Vertical Flex Vent Kit for North America (Part Vertical Terminations - Vertical Flex Vent Kit (Part #946-772) #946-772) Roof support Vertical Flex Vent Kit includes: Firestop spacer to prevent debris from falling into the •...
  • Page 61 Vertical Termination installation 5" (127 mm) x 8" (203 mm) Venting - Vertical Flex Vent Kit for North America installation (Part #946-772) 13. Slide the finished length up towards the flashing ensuring the length of pipe is a minimum of 2 feet (0.61 m) measured from installation 13.

  • Page 62: Vertical Flue Extension Kit (Part # 946-769)

    installation Vertical Flex Extension Kit for North America Part #946-769 Vertical Flue Extension Kit (Part # 946-769) 20 foot (6.1 m) flex pipe extension Vertical Flex Extension Kit includes: 5" (127 mm) inner pipe - 20 ft. (6.1 m) • 20 ft. flex pipe (inner & outer) with 10 spacers •...

  • Page 63: Ceiling Firestop / Firestop Spacer (Part # 946-770)

    installation Ceiling Firestop/Firestop Spacer (North America) VERTICAL FLUE EXTENSION KIT (APPROVED MODELS) Ceiling Firestop / Firestop Spacer (Part # 946-770) Part #946-770 (PART # 946-756) Used in conjunction with the 946-772 Vertical Flex Kit and 946-769 VERTICAL FLUE EXTENSION KIT (APPROVED MODELS) 11"...

  • Page 64: Non Power Vent Wiring Diagram

    installation Non-PV Wiring Diagram While the burner does not require a 120 V A.C. power supply, it is highly recommended as a primary power source. Batteries (4 AA) should be used as a secondary power source only. • Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation.

  • Page 65: Wiring The Unit (120 Volt Power Supply)

    installation Wiring the Unit (120 Volt Power Supply) The wiring for the unit should be completed before any finishing material is installed. All electrical wiring must be completed by a qualified electrician. 1. Remove the right access panel--see access panel removal instructions in this manual. DETAIL A SCALE 1 : 8 DETAIL A...
  • Page 66 2. Loosen 2 screws in locations shown below. installation 4. Bring the wiring from inside the wall through the opening created when the plate was removed in the previous step. 5. Wire the electrical box. • The receptacle and receptacle cover may be located in the manual pack and may need to be installed. 6.

  • Page 67: Vent Chart For Power Vent Only Horizontal Terminations - Inline Horizontal Vent Chart

    installation-power vent Vent Chart for Power Vent Only CV72EPV/CB72EPVCB40EPV/CC40EPV/CV40EPV/CV60EPV Horizontal Terminations - Inline Horizontal Vent Chart Inline Power Vent Vertical or Hortizontal Installation Instructions This section is for the Power Vent System installation. For a detailed installation information, refer Power Vent System installation instructions that comes with the Power Vent Kit.

  • Page 68: Vent Chart For Power Vent Only Horizontal Terminations - End Of Line Horizontal Vent Chart

    installation-power vent Vent Chart for Power Vent Only Horizontal Terminations - End of Line Horizontal Vent Chart For the complete Power Vent installation, refer the Power Vent System installation instruction in Power vent system Kit End Line Power Vent Kit # 946-535 RIGID PIPE: MUST USE RIGID PIPE ADAPTOR 770-994 AND 946-606 PIPE REDUCER TO 4"...

  • Page 69: Installation-Panels, Barriers, Faceplates

    installation-panels, barriers, faceplates Inner Glass Panel (Firebox Glass) Installation / Removal 3. From the front inside lower panel of the unit--pivot the 3 glass supports • Glass panels must be installed to operate the fireplace. into upright position as shown below. WARNING: GLASS HANDLING We recommend using the glass vacuum holders supplied by the manufacturer.
  • Page 70 installation-panels, barriers, faceplates 5. Pull the 3 lower glass gasket pads forward to release the glass. Gasket pad Push down on levers to lower glass panel 6. Support the glass with one hand and open the 9 lower clamps. 8. Carefully lean glass forward onto support. Glass panel--leaning on support •...

  • Page 71: End Inner Firebox Glass Panel Installation/Removal

    installation-panels, barriers, faceplates End Inner Firebox Glass Panel Installation/Removal TRANSPORTATION SUPPORT BRACKETS 2. Remove Side A and Side B firebox glass panels. 3. Locate the bracket holding the bottom end clamps and loosen the two screws to remove the bracket. 3RD ANGLE TOLERANCES UNLESS FIREPLACE PRODUCTS...
  • Page 72 installation-panels, barriers, faceplates 5. Attach the suction cup to the End glass panel. 6. Open the bottom and top clamps holding the glass panel. DETAIL B SCALE 1 : 8 DETAIL B SCALE 1 : 8 3RD ANGLE TOLERANCES UNLESS FIREPLACE PRODUCTS MAT'L : PROJECTION...

  • Page 73: Glass Barrier Installation & Glass Barrier Adjustment

    installation-panels, barriers, faceplates Glass Barrier Installation & Barrier Glass Adjustment Glass Safety Barrier Installation: 1. Ensure the fireplace is operating properly and all firebox glass and liner panels are installed prior to installing the glass safety barrier. 2. Remove the protective peel from the glass safety barrier and clean the inner surface. Identify the hooks on the glass safety barrier; these indicate the inner surface.
  • Page 74 installation-panels, barriers, faceplates 6. Holding the glass barrier in front of the unit, slide it up behind the top lip of the unit. Lift the barrier up as far as it goes, then hook the barrier onto the unit. Glass Barrier Adjustment Glass barrier adjustment Slide behind the top lip Lift up...
  • Page 75 installation-panels, barriers, faceplates Glass Barrier Adjustment Glass barrier adjustment If glass isn’t hanging straight, use a phillips screwdriver to adjust the angle. 9. Adjust the Side A and Side B barrier glass angle to be parallel with the End barrier glass. Clockwise = angles barrier out toward you Counter clockwise = angles barrier in towards the unit.

  • Page 76: Inner Black Steel/Enamel Panel Install (Part #457-907/457-908)

    installation-panels, barriers, faceplates CITY SERIES Inner Black Steel/Enamel Panel Installation (Part #457-907/457-908) Inner Black Steel/Enamel Panel Installation (Part #457-907/457-908) BEFORE YOU START 3. Drop the six #3 inner panels into the firebox, then drop the two #2 side covers, as shown below. Black Enamel Panels •...
  • Page 77 installation-panels, barriers, faceplates CITY SERIES There are 4 optional stoppers included in the manual pack which provide additional support to the glass barrier, if desired - install the stoppers prior to installation of the barrier glass. 7. Slide the glass barrier stopper in as shown below. DETAIL B SCALE 1 : 4 8.

  • Page 78: Inner Black Glass Panel Installation (Part #457-906)

    installation-panels, barriers, faceplates CITY SERIES Inner Black Glass Panel Installation (Part #457-906) INNER BLACK GLASS PANEL INSTALLATION (PART #457-906) 1. Turn off power and gas to unit and allow to cool to room tempera- 5. Install the bottom side bracket. ture.
  • Page 79 installation-panels, barriers, faceplates CITY SERIES 9. Install the 4 #5 outer front panels, 2 #5 panels per side as per below. 11. Slide the side outer #5 glass panels between the wall and the Also drop in two #7 panels, one in the front and one in the back. barrier stopper bracket.

  • Page 80: Installation-Media

    installation-media Burner and Firebox Media Options • Regardless of options chosen, fireglass must be installed on the burner in all cases. • Use supplied, approved media only with your fireplace. Use of other media can alter the unit's performance and cause damage, which is not covered under warranty.
  • Page 81 installation-media Firebeads + Fireglass Crushed Glass Iceburg Chips + Fireglass Spa Stones + Fireglass River Stones and Fireglass Volcanic, Ivory/Tan Basalt, + Natural Stones + Fireglass City Series CP60E |...

  • Page 82: Optional Log Set Installation

    installation-media CITY SERIES 60 Optional Log Set Installation CITY SERIES 60 - LOG INSTALLATION Read the instructions below carefully and refer to the images. If the logs are broken, do not use them in the unit until they are replaced. Broken logs can interfere with pilot operation. Improper positioning of the logs may create carbon build-up and alter the unit's performance, which is not covered under war- ranty.
  • Page 83 CITY SERIES 60 installation-media 4. The next steps are done at side A of the unit, where the valve and IFC board are located. 5. Install black fireglass (2lb) and glowing wool on the burner as shown below. 6. Locate the hole on the burner surround, on the left side of the pilot. Insert the pin underneath Log 1 into the hole on the burner surround. City Series CP60E | 920-393a 06.23.22...
  • Page 84 CITY SERIES 60 installation-media 7. Lay the log on the firebox. Ensure the bottom left end of the log is 3/4" away from the edge of the firebox. 8. Locate the hole on the right side of the pilot. 9. Insert the pin of Log 2 into the hole. Lay the log on the firebox, then measure the edge of the log to the side as shown below.
  • Page 85 CITY SERIES 60 installation-media 11. Connect the hole underneath Log 4 to the pin on Log 2. Rest Log 4 on the landing on Log 2. 12. Connect the hole underneath Log 5 to the pin on Log 2. Rest Log 5 on the landing on Log 2. 920-393a 06.23.22 City Series CP60E |...
  • Page 86 CITY SERIES 60 installation-media 13. Place Log 6 on top of Log 3, ensuring the pin on Log 3 is aligned with the hole on Log 6, and that Log 6 rests on the landing on Log 3. 14. Place Log 7 on top of Log 4, ensuring the pin on Log 4 is aligned with the hole on Log 7. 06.23.22 920-393a | City Series CP60E...
  • Page 87 CITY SERIES 60 installation-media 15. Install Log 8 between Log 3 and Log 4, as shown below. 16. Install Log 9 on top of the pilot as shown below. 920-393a 06.23.22 City Series CP60E |...
  • Page 88 CITY SERIES 60 installation-media 17. Install Log 11 beside Log 6. 18. Install Log 10 at the right end of the unit, as shown below. 06.23.22 920-393a | City Series CP60E...
  • Page 89 CITY SERIES 60 installation-media 19. Install the 3.5 lb box of black charcoal glass (optional) or 1lb box of Andriron embers (optional) around the burner. You can add a maximum of 30 pieces of Andriron embers on top of the burner. Make sure the burner surround is only 50% covered. Correct Coal Placement Final Placement City Series CP60E |...

  • Page 90: Horizontal Venting With Two

    7. When this appliance is serviced, check that Log Replacement the vent-air system was properly resealed & an authorized Regency dealer. Replacement glass reinstalled in accordance with the manufacturer's The unit should never be used with broken logs. is shipped already installed into the door frame.

  • Page 91: Aeration Adjustment

    maintenance Aeration Adjustment Minimum Air Shutter Opening The burner aeration is factory set, but may need adjusting due to the local NG, NG with logs, NG with volcanic stones: 3/16" (5 mm) gas supply or altitude. Open the air shutter for a blue flame or close for a LP, LP with logs, LP with volcanic stones: 3/8"...

  • Page 92: Bulb Replacement

    • Do not handle bulb with bare hands. Use packaging or a tissue to hold new bulb when replacing. Regency part# 911-208 Oven lamp assembly G9 120V/25W Light gasket Regency part# 911-072 Replacement bulb G9 120 Volt/25 watt Light glass Light cover Inner light cover reassembly order...

  • Page 93: Valve Replacement

    maintenance Valve Replacement 9. Disconnect the spark electrode, flame sense, and stepper motor from the Important: Always shut off gas supply/120 volt power prior to servicing the IFC board (see wiring diagram for location). gas valve. 1. Turn unit off and cool to room temperature. 2.

  • Page 94: Gas Maintenance - Recommended Annual Routine

    Gas Maintenance Gas Maintenance - Recommended Annual Routine Recommended Annual Routine Maintenance for Gas Fireplaces, Stoves and Inserts In order for your Regency appliance to continue to provide comfort to your home periodic maintenance must be performed to ensure it is operating at peak efficiency. The items in the list should be checked by a licensed gas service technician during the annual service check. Your unit may require more frequent maintenance checks if you notice any changes in how it operates. Operational changes to look for can include, but are not limited to, extended start up time, increased fan noise, residue/carbon build up, white build up on the glass/firebox, increased operating noise etc. Should any of these or other conditions arise, discontinue use and schedule a service check with your local licensed gas technician. The list below shows items your licensed service technician will need to check and service at least annually. Clean Inspect Check • Glass • Pilot assembly • Voltage on thermocouple/thermopile (mil- • Interior bricks / panels • Burner livolt models) •...

  • Page 95: Parts List

    parts list Main Assembly 4, 5, 6, 7, 8, 9,10,11 5'$1*/( 72/(5$1&(681/(66 ),5(3/$&(352'8&76 0$7/ 352-(&7,21 27+(5:,6(67$7(' ,17(51$7,21$/ 6+($5381& ',0(16,216 352&(66 &5,7,&$/ &30$,1$66(0% 6&$/( 3$57 63(&,),('72/(5$1&( '21276&$/( '5$:,1* 0('5$/,1 3$5712 '$7( 5() 5()(5(1&(21/< 81,76,1,1&+(6 $1*8/$5 '$7( (&1 6,*1 7+,6'5$:,1*,67+(3523(57<2))3,/7',70$<127%(&23,(',1:+2/(25,13$5725',6&/26('72$7+,5'3$57<:,7+28728535,25:5,77(1&216(17 City Series CP60E |...
  • Page 96 parts list Main Assembly Item Part # Description Item Part # Description 450-574/P Valve Assembly - NG 904-658 Inlet Flex Line Gas SS Steel 24 inch 450-576/P Valve Assembly - LP 904-943 Bracket Dormont Orifice Mount 10-BZ001-19.5 911-188 Novasit Gas Valve - NG 0.885.009 911-182 IFC Digital Fireplace Control Fuse 3.15 amp Fast Acting...

  • Page 97: Accessories

    Individual Glass Gasket Parts 905-001 Phillip Offset Screwdriver (Removal Of Finish- ing Lip) Item Part # Description 918-835 Decal Logo Regency / Flame Sit Remote 726-017 Gasket Novatec Top Right (each) 918-876 Decal Remote Quick Reference GTMF 726-020 Gasket Novatec Sides (each) 946-634...

  • Page 98: Upper Glass Clamps

    parts list Upper Glass Clamps UPPER GLASS CLAMPS SIDES UPPER GLASS CLAMPS SIDES DETAIL A SCALE 1 : 8 DETAIL A SCALE 1 : 8 3RD ANGLE TOLERANCES UNLESS FIREPLACE PRODUCTS MAT'L : PROJECTION OTHERWISE STATED 3RD ANGLE TOLERANCES UNLESS FIREPLACE PRODUCTS INTERNATIONAL MAT'L :...

  • Page 99: Power Vent-End Of Line (Part # 946-535)

    parts list Power Vent-End of Line (Part # 946-535) Part Number Description 911-112/P Pressure Switch/SEnsor (includes bracket) 911-244/P Power Vent Fan Assembly 905-017 Straight Wire Connector/Clamp 3RD ANGLE TOLERANCES UNLESS FIREPLACE PRODUCTS MAT'L : PROJECTION OTHERWISE STATED INTERNATIONAL SHEAR/ PUNCH/ FORM DIMENSIONS PROCESS : 0.000...

  • Page 100: Power Vent - Inline (Part # 666-945)

    parts list Power Vent - Inline (Part # 666-945) Part Number Description 911-305/P 120 Volt Fan Motor 911-112 Vacuum Switch 911-047 Silicone Hose (sold per foot/1 foot required) 911-047 Silicone Hose (sold per foot/1 foot required) 3RD ANGLE TOLERANCES UNLESS FIREPLACE PRODUCTS MAT'L : PROJECTION...
  • Page 101 notes City Series CP60E |...

  • Page 102: Warranty

    FPI is not responsible for results or costs of workmanship of unauthorized FPI dealers or agents in the negligence of their service work. | City Series CP60E Revision Date: February 2019 Regency Gas Products Warranty...
  • Page 103 Freight damages for products or parts are not covered under the terms of the warranty. Products made or provided by other manufacturers and used in conjunction with the FPI appliance without prior authorization from FPI may void this warranty. City Series CP60E | Revision Date: February 2019 Regency Gas Products Warranty...
  • Page 104 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com/Customer-Care/Warranty-Registration.aspx...
  • Page 105 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
  • Page 106 warranty | City Series CP60E...
  • Page 108 Dealer Name & Address: ________________________________________________ ____________________________________________________________________ Installer: ____________________________________________________________ Phone #: ____________________________________________________________ Date Installed: ________________________________________________________ Serial #:_____________________________________________________________ Printed in Canada Regency and City Series are trademarks of FPI Fireplace Products International Ltd. © Copyright 2023, FPI Fireplace Products International Ltd. All rights reserved.

This manual is also suitable for:

City seriesCity cp60e-ngCity cp60e-lp

Table of Contents
