ACB60E DIRECT VENT
STYLE
Three sided
Corner Conversion
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in
the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas
supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or
the gas supplier.
Installer: Please complete the details on the back cover and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
920-317a
City Series ®
MODEL
ACB60ENG / ACB60ELP / ACB60EULP
Owners &
Installation Manual
www.regency-fire.com.au
LISTING AND CODE APPROVALS
These gas appliances were
tested in accordance with AS/
NZS 5263.0 & AS/NZS 5263.1.8
and certified by IAPMO for instal-
lation and operation as described
in these instructions.
Must be installed as per
AS/NZS5601.
Your unit should be serviced an-
nually by an authorised service
person.
www.regency-fire.com.au
04.07.21
Advertisement
Table of Contents
Related Manuals for Regency City ACB60ENG
Summary of Contents for Regency City ACB60ENG
- Page 1 City Series ® Owners & ACB60E DIRECT VENT Installation Manual STYLE MODEL www.regency-fire.com.au Three sided ACB60ENG / ACB60ELP / ACB60EULP Corner Conversion WARNING FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious LISTING AND CODE APPROVALS injury, death, or property damage.
- Page 2 The ACB60E City Series is approved by Intertek for both safety and efficiency. City Series appliances also bear Regency's mark, signifying our promise to provide you with economy, comfort and security for many trouble-free years to follow.
-
Page 3: Table Of Contents
table of contents Owner's information Horizontal Terminations - Rigid Pipe 127 mm x 203 mm ....58 Horizontal Venting with Two 90 Elbows .......... 58 Copy of Safety Decal ................4 Horizontal Venting with Three 90 Elbows ........58 Dimensions - Bay Install ..............5 Vertical Terminations - Rigid/Flex Pipe 127 mm x 203 mm .... -
Page 4: Copy Of Safety Decal
Check the label on the unit; if there is a difference between the information on it and the infromation below, the label on the unit is correct. Copy of Safety Decal Regency Gas Fireplace Distributed by: Propane... -
Page 5: Dimensions - Bay Install
dimensions Dimensions - Bay Install Note: Height dimension is taken with leveling legs fully inserted. Height may vary depending on the length of the leveling legs when unscrewed or extended. Note: These units are non load bearing. ALL PICTURES / DIAGRAMS SHOWN THROUGHOUT THIS MANUAL ARE FOR ILLUSTRATION PURPOSES ONLY. ACTUAL PRODUCT MAY VARY DUE TO PRODUCT ENHANCEMENTS. -
Page 6: Dimensions - Corner Install
dimensions Dimensions - Corner Install " " 905 mm 905 mm 905 mm 905 mm 5" 8" 204 mm 127 mm 127 mm 204 mm " 1837 mm 1837 mm " " 1810 mm 515 mm 1810 mm 515 mm "... -
Page 7: Gas Connection - Back Of Unit
dimensions Gas Connection - Back of Unit 35 mm 8 " 8 " 35 mm 2 " 2 " 64 mm 64 mm 8 " 5" 4 " Gas Connection - Bottom of Unit FRONT OF UNIT GAS VALVE 8 " 416 mm OPENING AT UNIT BASE BACK OF UNIT... -
Page 8: Electrical Connection - Bottom Of Unit
dimensions Electrical Connection - Bottom of Unit FRONT OF UNIT 416 mm 8 " OPENING AT UNIT BASE BACK OF UNIT Electrical Connection - Side of Unit 8 " 5" 4 " RIGHT SIDE 8 | City Series ACB60E... -
Page 9: Important Message
owner's information Important Message WE RECOMMEND REMOVING THE CHILDREN AND ADULTS SHOULD BE SAVE THESE INSTRUCTIONS GLASS WITH THE GLASS VACUUM ALERTED TO THE HAZARDS OF HIGH HOLDERS SUPPLIED BY THE MANU- SURFACE TEMPERATURES, ESPE- FACTURER. LOWER THE GLASS TO City Line direct vent fireplaces must be installed CIALLY ON THE FIREPLACE GLASS, in accordance with the instructions in this manual;... -
Page 10: First Fire
owner's information First Fire Normal Operating Sounds Of Gas Appliances The FIRST FIRE in your fireplace is part of the paint curing process. To ensure that the paint is You may hear some sounds emanating from your properly cured, it is recommended that you burn gas appliance. -
Page 11: Lighting Procedure
owner's information Lighting Procedure IMPORTANT: The remote control system supplied with this appliance has Note: The first try for ignition will last approximately 60 seconds. If there is no several options for starting/operating the appliance using the battery holder flame ignition (rectification) the board will stop sparking for approximately and ON/OFF key on the hand held transmitter. -
Page 12: Copy Of The Lighting Plate Instructions
owner's information Copy of the Lighting Plate Instructions FOR YOUR SAFETY READ BEFORE LIGHTING SUITABLE ONLY FOR INDOOR INSTALLATION This appliance must be installed in accordance with local codes, if any. If none, follow the current AS/INZS 5601. WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. -
Page 13: Proflame Ii Remote Control Operating Instructions
owner's information Proflame II Remote Control Operating Instructions IMPORTANT:The Proflame Transmitter 2 is an integrated part of the TECHNICAL DATA Proflame 2 System, which consists of these elements: REMOTE CONTROL • Proflame 2 Transmitter, to be used in conjunction with: •... - Page 14 owner's information Temperature indication Display Remote-Flame Control With the system in the "OFF" position, press the Thermostat Key and The Proflame has six (6) flame levels. With the system on, and the flame the Mode Key at the same time. Look at the LCD screen on the transmit- level at the maximum in the appliance, pressing the Down Arrow Key ter to verify that a C or F is visible to the right of the room temperature once will reduce the flame height by one step until the flame is turned off.
- Page 15 owner's information Smart Thermostat (Transmitter Operation) Remote dimmer control (Light)** The auxiliary function controls the AUX power outlet by the dimmable The Smart Thermostat function adjusts the flame height in accordance light control. To activate this function use the Mode Key (fig. 1) to index to the difference between the set point temperature and the actual room to the AUX icon (fig.
- Page 16 owner's information Continuous Pilot/Intermittent Pilot (CPI/IPI) selection 5. "Clr" will remove a mode—use the up or down arrow while holding down ON/OFF and MODE (mode icon will disappear once removed). Note: Power vent models do not have a Continuous 6. Use the "MODE" button to move to the next function. Pilot option.
-
Page 17: Front & Side Glass Barrier Removal
owner's information Front & Side Glass Barrier Removal Note: Only the front glass barrier is shown in diagrams - follow same procedure for side glass barrier removal. OWNERS MANUAL Glass barrier removal video Glass safety barrier removal 1. Prepare a soft, scratch resistant surface to place the glass (i.e. large sheet or clean drop cloth). 2. -
Page 18: Glass Barrier Adjustment
owner's information Glass Barrier Adjustment Glass barrier adjustment If glass isn’t hanging straight, use a phillips screwdriver to adjust the angle. Clockwise = angles barrier out toward you Counter clockwise = angles barrier in towards the unit. Slide the screwdriver straight up at the two indicator slots. To adjust the side glass, remove the screws at the top of the panel If side glass height needs adjustment, follow the next and move the glass up or down. -
Page 19: Inner Glass Panel Installation / Removal
owner's information Inner Glass Panel Installation / Removal Note: glass panels must be installed to operate fireplace 3. From the front inside lower panel of the unit--pivot the glass support into upright position as shown below. WARNING: GLASS HANDLING We recommend using the glass vacuum holders supplied by the manufacturer. - Page 20 owner's information 5. Pull the 3 lower glass gasket pads forward to release the glass. Gasket pad Push down on levers to lower glass panel 6. Support the glass with one hand and open the 9 lower clamps. 8. Carefully lean glass forward onto support. Glass panel--leaning on support NOTE: The firebox glass may remain propped on the glass supports to clean the interior surface.
-
Page 21: Inner Glass Panel (Firebox Glass) Installation / Removal - Side Glass
owner's information Inner Glass Panel (Firebox Glass) Installation / Removal - Side Glass 4. Gently move bottom of side glass panel into the support channel as shown 1. Open 2x lower clamps by turning 90°. in diagram below. 2. Pull glass gasket pad forward to release glass. Note: if gasket pad won't open--check that all clamps are turned a full 90°. -
Page 22: Optional Front Barrier Glass Stoppers Installation / Removal
owner's information Optional Front Barrier Glass Stoppers Installation / Removal There are 4 optional stoppers (2 side/2 front) included in the manual pack 3. Install glass stopper (if desired) by sliding stopper assembly between which provide additional support to the glass barrier, if desired--install the unit and panel - the stopper assembly will attach to the unit via a magnet, stoppers prior to installation of the barrier glass. -
Page 23: Bulb Replacement
NOTE: Do not handle bulb with bare hands. Use packaging or a tissue to hold new bulb when replacing. Regency Part# 911-208 Oven Lamp Assembly G9 240V/25W Regency Part# 911-300 Replacement Bulb G9 240 Volt/25 watt Light gasket Light glass... -
Page 24: Maintenance Instructions
Regency dealer only. Replacement glass is shipped When cleaning the logs, use a soft clean paint being exposed to cold weather. -
Page 25: Installer's Information
installer's information General Safety Information Installation Checklist This includes: 1. The appliance installation must conform with 1. Locate appliance. Refer to the following sections: 1. Clocking the appliance to ensure the correct local codes or, in the absence of local codes, a) Locating Your Fireplace firing rate (rate noted on label 41.1 MJ/h NG, with the current Installation and Building Codes. -
Page 26: Locating Your Gas Fireplace - Bay Install
installer's information Locating Your Gas Fireplace - Locating Your Gas Fireplace - Bay Install Corner Install 1. When selecting a location for your fireplace, 1. When selecting a location for your fireplace, ensure that the clearances are met. ensure that the clearances are met. 2. -
Page 27: Unit Assembly Prior To Installation
installer's information Unit Assembly Prior to Installation Before you Start - Removing the Unit from the Pallet Remove the screws securing the unit to the pallet Due to the size and weight (208 kg shipping weight) of the ACB60E--lifting and moving the unit will require 4 people. Place a length (long enough to get a solid grip on each side) through the opening on each side of the unit as shown. - Page 28 installer's information Access Panel Removal Access panel removal The front access panels (x3) and one (x1) on the right side The front access panels (x3) may be removed for ease of (facing unit front) may be removed for ease of hooking up gas hooking up gas and electrical--prior to finishing.
-
Page 29: Clearances (3-Sided)
installation Clearances (3-sided) The clearances listed below are minimum distances unless otherwise stated. A major cause of chimney related fires is failure to maintain required clearances (air space) to combustible materials. It is of the greatest importance that this fireplace and vent system be installed only in accordance with these instructions. Flue Clearances to Combustibles Clearance Dimension... -
Page 30: Clearances
installation Clearances opening opening Floor to ceiling with top opening Full framing with vents in front/2 sides or top opening opening Full framing with low vents in front or 2 sides Full framing with vents in front or 2 sides | City Series ACB60E... -
Page 31: Clearances - Corner Install
installation Clearances - Corner Install The clearances listed below are minimum distances unless otherwise stated. A major cause of chimney related fires is failure to maintain required clearances (air space) to combustible materials. It is of the greatest importance that this fireplace and vent system be installed only in accordance with these instructions. -
Page 32: Mantel Clearances
installation Mantel Clearances Combustible mantel clearances from top of front facing are shown in the diagram on the right. 152 102 13 mm Drywall, wood, wood panel, etc. 305 mm 229 mm 133 mm To Bottom of Top of Fireplace Fireplace Opening Opening... -
Page 33: Framing Dimensions - Bay Install
installation Framing Dimensions - Bay Install NOTE: Framing may be constructed of combustible material and does not require steel studs. Framing Description ACB60E Dimensions Framing Height 1137 mm Framing Width 1810 mm Framing Depth 516 mm Minimum Height to Combustibles 2038 mm Vent Centerline Height 1478 mm... -
Page 34: Framing Dimensions Corner Kit - Corner Install (Right Corner)
installation Framing Dimensions Corner Kit - Corner Install (Right Corner) NOTE: Framing may be constructed of combustible material and does not require steel studs. Note: A combined minimum of 1161 Framing square centimeters of open area is Description Corner Kit Dimensions required for the convection air outlet to cool the enclosure. -
Page 35: Framing Dimensions Corner Kit - Corner Install (Left Corner)
installation Framing Dimensions Corner Kit - Corner Install (Left Corner) NOTE: Framing may be constructed of combustible material and does not require steel studs. Note: A combined minimum of Framing 1161 square centimeters of open Description Corner Kit Dimensions area is required for the convection air outlet to cool the enclosure. -
Page 36: Corner Installation Kit (Black) - Assembly Steps
CB60E CORNER installation CB60E CORNER INSTALLATION KIT (BLACK) - ASSEMBLY STEPS Corner Installation Kit (Black) - Assembly Steps 1. Decide on left or right install. Take removable trim off side to be con- 4. Slide outer side panel down onto the two screws in the firebox body. verted. Tighten screws with screwdriver. 2. Install trim guide for left or right install to the outer side panel. 5. Screw in the three self-tapping screws at the top of the outer side panel to attach it to the firebox. 3. Screw removable trim on and bend tabs closest to the finishing trim 6. Unit can be placed in framing and finishing materials added at this inwards 90 degrees. point. | City Series ACB60E 11.13.19 920-175... - Page 37 CB60E CORNER installation 10. Install the inner panel for the corner conversion by wedging it into the 7. Lift the glass stop and open the glass. inner lower liner panels. 8. Install lower inner liner panels. 11. Slide the inner side panel in by wedging it between the side glass and the back liner panels. 9. Install the back panels by angling the bottom of each panel towards 12. Once the inner side panel is wedged in place, tighten the hanger the base of the firebox and then pushing them in. screws for the back liner panels. City Series ACB60E | 37 920-175 11.13.19...
- Page 38 CB60E CORNER installation 13. Close the glass, turn the glass lifters to the up position, and lock all 16. Slide the corner panel over to the outer side panel until contact with the upper and lower clamps. magnets is made. 14. Install outer liner panels - there will be two left over. 17. Install barrier glass as per instructions in the manual. 15. Slide the corner panel up and in to secure it. | City Series ACB60E 11.13.19 920-175...
-
Page 39: Optional Framing Kit
installation CITY SERIES Optional Framing Kit Optional Framing Kit Note: Unit nailing strips are not required (and can be recycled) when using Tools/hardware required: the framing kit. - Level - Stud finder - Cordless screwdriver - Phillips bit - 8 mm hex head bit - 51 mm x 76 mm wood screws (minimum 16) - Torch Note: Extra screws are provided to assemble this kit. - Page 40 CITY SERIES installation 5. Secure the unit with framing to the wall studs with 64 mm - 76 mm wood 8. Attach 2 x Part G to the previously installed Part J parts with 2 screws screws (not supplied). Use 8 screws and secure to 4 studs minimum. at each end.
- Page 41 CITY SERIES installation 11. Install 4 horizontal mid braces (Part K) with one screw on each end 13. Install 2 top and 2 inner diagonal supports (Part D) with 2 screws (installed from the top). at each end. tooltip tooltip Part K Part D 12.
-
Page 42: Chase Vent Installation (White Front)
CITY SERIES installation ACB60E/ACV60E CHASE VENT INSTALLATION (WHITE FRONT) Chase Vent Installation (White Front) Framed opening must be between 76 mm and 89 mm tall and at least 1530 mm wide to accommodate Framed opening must be between 76 mm and 89 mm tall and at least 1530 mm wide to accommodate the chase vent. The top of the chase vent opening must be 51 mm or less from the top of the chase enclosure. -
Page 43: Wall Board/Plasterboard Installation
installation Wall Board/Plasterboard Installation WARNING! Risk of Fire! Comply with all minimum clearances to combustibles as specified. Finishing Instructions It is important to follow the framing and finishing instructions to ensure proper placement of fireplace into the surrounding framing/finishing materials. Wall board materials 13 mm. -
Page 44: Framing And Finishing Inset Installations
installation Framing and Finishing Inset Installations 1. Frame in the enclosure for the unit with framing material Note: When constructing the framed opening ensure there is access to install the gas lines,electrical. Also the wiring harness must be wall mounted using the receptacle provided with the appliance. -
Page 45: Typical Installations
installation Typical Installations Flush Install Recessed Install 51 mm 1161 cm min. 1161 cm min. 4 cm x 9 cm shown Max. 4 cm x 14 cm 133 mm. 13 mm. 914 mm. City Series ACB60E | 45... -
Page 46: Typical Installations
installation Typical Installations Maximum TV Recess Flush TV with Hearth 51 mm 51 mm 1161 cm min. 1161 cm min. Max. 4 cm x 14 cm 13 mm. 13 mm. Note: The TV mounting bracket cannot be secured directly to the appliance. It must be secured to framing. The TV depicted in the picture may need to be higher depending on the style of TV mounting bracket used. -
Page 47: Finishing
installation Finishing CV72 Finishing Flush Install Example - Front edge of side liner panels must not be covered by nishing material or - Loosen screws using supplied O set removal of the Firebox Glass will not be Screwdriver and remove bottom and - Finish up to trim on all 4 sides possible side trim pieces... -
Page 48: Chase Venting
This can be achieved in a number of ways, including the examples shown below. Warning: DO NOT cover or place objects in front of the air outlet(s). Regency Chase Vent Dimensions: Custom chase vent 76 mm x 1524 mm (1161 cm Example dimensions: 63.5 mm x 1829 mm (1161 cm... -
Page 49: Wall Mount On / Off Switch And Battery Holder Installation
installation Wall Mount On / Off Switch and Battery Holder Installation (Required for all installations) IMPORTANT INSTALLATION NOTE: The Battery Holder must be placed inside the supplied (Low Voltage) junction type wall box and installed into the wall only. DO NOT INSTALL WITHIN THE CONFINES OF THE FIREPLACE SWITCH MUST BE ACCESSIBLE Battery Holder Installation 1. -
Page 50: Exterior Flue Termination Locations
installation Exterior Flue Termination Locations FIGURE 6.2 (in part): LOCATION OF FLUE TERMINALS OF BALANCED FLUE AS/NZ 5601, ROOM-SEALED, FAN ASSISTED OR OUTDOOR APPLIANCE | City Series ACB60E... -
Page 51: Clearances
installation Clearances Minimum clearances (mm) Ref. Item Natural Draught Assisted Below eaves, balconies and other projections: Appliances up to 50 MJ/h input Appliances up to 50 MJ/h input From the ground, above a balcony or other surface* From a return wall or external corner* From a gas meter (M) (see Note 5) (see Clause 5.11, 5.9 for vent terminal location of regulator) 1000... -
Page 52: 127 Mm X 203 Mm Rigid Pipe - Cross Reference Chart Only
127 MM X 203 MM RIGID PIPE CROSS REFERENCE CHART Components from different Manufacturers may not be mixed. Not all rigid pipe components are available directly from Regency. Note: Olympia Ventis DV venting is only approved for certain models. See list of approved models in cross-reference chart. - Page 53 Snorkel Termination 356 mm 58DVA-SNK14 Snorkel Termination 914 mm 58DVA-SNK36* Restrictor Disk Colinear Flex Connectors * Not available from Regency 946-604/P Simpson Direct Vent or Astro Cap -Vent Guard (Optional) 946-623/P AstroCap XL Horizontal Cap 770-994 Rigid Pipe Adaptor (Must use with all rigid piping)
-
Page 54: Vent Restrictor Position
installation Vent Restrictor Position Vent restriction is required for certain venting installations, see the diagrams in the "Venting Arrangements" section to determine if they are required for your installation. The Vent Restrictor plate is installed on the appliance at Set 0. To set the vent restriction as indicated in the venting arrangements diagrams, refer to the following instructions;... -
Page 55: Venting Introduction
Refer to the "Vent Restrictor Position" section for details on how to change the vent restrictor from the factory setting of Set 0 to Set 2 if required. Note: For horizontal terminations the Regency Direct Vent Flex System may be used for installations with a maximum continuous vent length of up to 3 meters. -
Page 56: Horizontal Terminations - Flex Vent 127 Mm X 203 Mm
S.S. screws #8 x 1-1/2” drill point 10) vinyl siding standoff Notes: 1. Liner sections should be continuous without any joints or seams. 2. Only Flex pipe purchased from Regency ® may be used for Flex installations 3. Horizontal vent must be supported every 0.9 m. -
Page 57: Horizontal Terminations - Rigid Pipe 127 Mm X 203 Mm
installation Horizontal Terminations - Rigid Pipe 127 mm x 203 mm The minimum components required for a basic horizontal termination are: Horizontal Termination Cap Rigid Pipe Adaptor (770-994) Wall Thimble Length of pipe to suit wall thickness (see chart) Horizontal Termination Cap Wall thickness is measured from the back standoffs to the inside mounting surface of termination cap. -
Page 58: Horizontal Terminations - Rigid Pipe 127 Mm X 203 Mm
installation Horizontal Terminations - Rigid/Flex Pipe 127 mm x 203 mm The diagrams below show examples of horizontal termination arrangements using one, two, or three 90 elbows (two 45 elbows equal one 90 elbow). 1. A maximum of three 90 elbows are permitted. -
Page 59: Vertical Terminations - Rigid/Flex Pipe 127 Mm X 203 Mm
installation Vertical Terminations - Rigid/Flex Pipe 127 mm x 203 mm The minimum components required for a basic vertical termination are: High Wind Cap Vertical Termination Cap Rigid Pipe Adaptor (Dura Vent Only) Lengths of pipe to adequately penetrate roof. Flashing (as required per AS/NZS 5601-2013, to be supplied by installer.) Flashing (not supplied) -
Page 60: Vertical Terminations - Rigid/Flex Pipe 127 Mm X 203 Mm
installation Vertical Terminations - Rigid/Flex Pipe 127 mm x 203 mm • Two 45 elbows equal to one 90 elbow. Maximum of six 45 elbows allowed. • Vent must be supported at offsets. • Minimum distance between elbows is 0.3 m. •... -
Page 61: Elbows (1 - 90 O = 2 - 45 O )
installation Venting Arrangement With Straight Vertical Venting and/or With a Max. of Two 90 Elbows (1 - 90 2 - 45 Horizontal (meters) The shaded area in the diagram shows all allowable combinations of straight vertical and offset to vertical terminations, using two elbows, with Rigid/Flex Pipe Venting Systems. -
Page 62: Vertical Termination - 127 Mmx 203 Mm Flueing - Vertical Flex Kit
Termination Cap installation Storm Collar Vertical Termination Flashing 127 mm x 203 mm Flueing - Vertical Flex Vent Kit (946-772) Vertical Termination - 127 mmx 203 mm Flueing - Vertical Flex Kit (Part 946-772) Roof support Must choose 1 of the following: Firestop spacer to prevent debris Part # Description... -
Page 63: Vertical Termination - 127 Mmx 203 Mm Flueing - Vertical Flex Kit (Part 946-772)
installation Vertical Termination 127 mm x 203 mm Flueing - Vertical Flex Vent Kit (946-772) Vertical Termination - 127 mmx 203 mm Flueing - Vertical Flex Kit (Part 946-772) installation 13. Slide the finished length up towards the flashing ensuring the length installation 13. -
Page 64: Vertical Flue Extension Kit (Approved Models) (Part # 946-769)
installation Vertical Flue Extension Kit Part #946-769 Vertical Flue Extension Kit (Approved Models) (Part # 946-769) 6.1 m flex pipe extension VERTICAL FLUE EXTENSION KIT (APPROVED MODELS) Used in conjunction with the 946-772 Vertical Flex Kit for vertical 127 mm inner pipe - 6.1 m installations. -
Page 65: Direct Flue Zero Clearance Top Exit Vertical Flue Kit - Installation Instructions
installation Direct Flue Zero Clearance Top Exit Vertical Flue Kit - Installation Instructions This flue kit has been manufactured for use with ACB60E and to be installed in accordance with AS/NZS 5601. To ensure safety and correct unit operation this flue kit must be installed as outlined in these instructions. -
Page 66: High Elevation
PROPANE SYSTEM DATA Min. Supply Pressure 2.75 kPa Manifold Pressure High 2.62 kPa Manifold Pressure Low 0.63 kPa Note: If you have an incorrect flame pattern, contact your Regency dealer for ® Maximum Input 38 MJ/h further instructions. Minimum Input 19.4 MJ/h... -
Page 67: Wiring Diagram
installation Wiring Diagram (Do not cut the earth terminal off under any Caution: Ensure that the wires do not No electrical power supply is required for the gas circumstances.) control to operate. 240 Volt AC power is needed touch any hot surfaces and are away from for the lights. -
Page 68: Glass Barrier Installation
installation Glass Barrier Installation OWNERS/INSTALLATION MANUAL Note: Front glass barrier only shown in diagram - follow same procedure for side glass barrier removal. Glass barrier removal video Glass barrier installation 1. Ensure fireplace is operating properly and all firebox glass, and liner panels are installed prior to installing the glass safety barrier. -
Page 69: Glass Barrier Adjustment
installation Glass Barrier Adjustment Glass barrier adjustment If glass isn’t hanging straight, use a phillips screwdriver to adjust the angle. Clockwise = angles barrier out toward you Counter clockwise = angles barrier in towards the unit. Slide the screwdriver straight up at the two indicator slots. To adjust the side glass, remove the screws at the top of If side glass height needs adjustment, follow the next the panel and move the glass up or down. -
Page 70: Propane / Ulpg Conversion Instructions
ACB60E/ACV60E CITY SERIES installation PROPANE / ULPG CONVERSION INSTRUCTION Propane / ULPG Conversion Instructions ACB60E/ACV60E using SIT 885 NOVA Gas Valve THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION! 6. Disconnect the Cable coming from the Pressure Regulator Motor. WARNING This conversion kit shall be installed by a qualified ser- Cable from motor... - Page 71 ACB60E/ACV60E CITY SERIES installation 15. Unscrew the pilot orifice with the Allen key; then replace with the 12. Loosen 8 screws in locations shown below (4 at front and 4 at rear)— propane/ULPG pilot orifice and the pilot cap, provided in the kit. slide burner to the left away from the orifice and lift out.
-
Page 72: Optional Fan Ducting Kit Installation
ACB40E/ACC40LE/ACC40RE/ACV40AC/ACB60E/ACV60E installation OPTIONAL FAN DUCTING KIT INSTALLATION Optional Fan Ducting Kit Installation Note: ACB40E/ACC40LE/ACC40RE/ACV40AC - The 656-995 HeatWave adapter and 946-596 Aluminum flex (4.5m) must be purchased separately. ACB60E/ACV60E - The 946-766 HeatWave adapter and 946-596 Aluminum flex (4.5m) must be purchased separately. LISTINGS AND CODE GENERAL INFORMATION If you require more than 4.5m please purchase the... - Page 73 installation ACB40E/ACC40LE/ACC40RE/ACV40AC/ACB60E/ACV60E OPTIONAL FAN KIT INSTALLATION 9. Attach oval to round collar/base adapter as- NOTE: Installation of Fan Kit should be done prior to Air Duct sembly (assembled in step 8) to unit in location installation of the wall. shown below with 4 screws. 2) Mount and secure the fan housing assembly to framing members, the front of the fan housing will NOTE: Install the HeatWave adapter on the left...
- Page 74 installation WIRING DIAGRAM ON/OFF NOTE: The wires (in dotted lines) Switch and the wire nuts are not supplied. Wire Nut CAUTION: Label all wires prior to dis- Wire Nuts connection when servicing controls. Wiring errors can cause improper and Brown Brown (Hot) Wire dangerous operation.
-
Page 75: Inner Black Panel Installation
CITY SERIES installation Inner Black Panel Installation ACB60 INNER ENAMEL PANEL INSTALLATION 2. Install glass stopper (if desired) by sliding down the outside of the outer side panel. ACB60E - 7 outer panels and 8 inner panels. Turn off gas and power to unit and allow to cool to room tempera- ture. - Page 76 CITY SERIES installation 5. Install middle outer panel. 6. Install glass stopper (if desired) by sliding stopper assembly between unit and panel - the stopper assembly will attach to the unit via a magnet. Adjust position of glass stopper as required. 7.
-
Page 77: Inner Enamel Panel Installation
installation Inner Enamel Panel Installation Black Enamel Panels — Handling Instructions • Black Enamel panels must be inspected for scratches and dimples prior to installation. All claims to be recorded at this time. Claims for damage after installation will not receive consideration. •... - Page 78 CITY SERIES installation 5. Install middle outer panel. 6. Install glass stopper (if desired) by sliding stopper assembly between unit and panel - the stopper assembly will attach to the unit via a magnet. Adjust position of glass stopper as required. 7.
-
Page 79: Burner And Firebox Media Options
installation Burner and Firebox Media Options Spread the media evenly over the burner. Ensure the glass/stones do not overlap excessively as this will affect the flame pattern. IMPORTANT NOTE: Only the supplied approved media are to be used with these fireplaces. Use of any other type of glass or stones can alter the unit's performance. Any damage caused by the use of any unapproved glass or stones will not be covered under warranty. -
Page 80: Optional Driftwood Log Set Installation
ACB60E/ACV60E CITY SERIES installation Optional Driftwood Log Set Installation CITY SERIES - LOG INSTALLATION AUSTRALIA Read the instructions below carefully and refer to the images. If the logs are broken do not use the unit until they are replaced. Broken logs can interfere with pilot operation. Improper positioning of the logs may create carbon build-up and alter the unit's performance, which is not covered under warranty. - Page 81 ACB60E/ACV60E CITY SERIES installation 6. Place Log 1 on top of the log guide. The pin under Log 1 and the log 10. Insert the pin of Log 5 into the hole on the left side of the pilot. Position guide will act as a guide for Log 1's proper positioning.
- Page 82 ACB60E/ACV60E CITY SERIES installation 14. To install Log 8, line up the pin locator on Log 8 with the pin on Log 2 17. To install Log 11, line up the pin locator on Log 11 with the pin on and rest the other end of Log 8 on the landing on Log 4, as shown below.
-
Page 83: Optional Split Wood Log Set Installation
ACB60/ACV60E CITY SERIES installation CITY SERIES 60 - SPLIT WOOD LOG INSTALLATION (AUSTRALIA) Optional Split Wood Log Set Installation Read the instructions below carefully and refer to the images. If the logs are broken do not use the unit until they are replaced. Broken logs can interfere with pilot operation. - Page 84 ACB60/ACV60E CITY SERIES installation 6. Place Log 1 on top of the log guide. The log guide will act as a guide 10. Insert the pin of Log 5 into the hole on the left side of the pilot. Position for the proper positioning of Log 1.
- Page 85 ACB60/ACV60E CITY SERIES installation 14. To install Log 8, line up the pin locator on Log 8 with the pin on Log 4 17. To install Log 11, line up the pin locator on Log 11 with the pin on Log and rest the other end of Log 8 on the landing on Log 2, as shown below.
-
Page 86: Optional Birch Wood Log Set Installation
ACB60E/ACV60E CITY SERIES installation CITY SERIES - BIRCH WOOD LOG INSTALLATION (AUSTRALIA) Optional Birch Wood Log Set Installation Read the instructions below carefully and refer to the images. If the logs are broken do not use the unit until they are replaced. Broken logs can interfere with pilot operation. - Page 87 ACB60E/ACV60E CITY SERIES installation 6. Place Log 1 on top of the log guide. The log guide will act as a guide 10. Insert the pin of Log 5 into the hole on the left side of the pilot. Position for the proper positioning of Log 1.
- Page 88 ACB60E/ACV60E CITY SERIES installation 14. To install Log 8, line up the pin locator on Log 8 with the pin on the 17. To install Log 11, line up the pin locator on Log 11 with the pin on Log left-most side of Log 1.
-
Page 89: Maintenance
& reinstalled in accordance with the rigidity. purchase your replacement from an authorized manufacturer's instructions. Regency dealer only. Replacement glass is shipped Log Replacement already installed into the door frame. Reinstall as per 8. Verify operation after servicing. Glass Installation in the "Glass Installation" section. -
Page 90: Valve Replacement
maintenance Valve Replacement tooltip Important: Always shut off gas supply/240 volt power prior to servicing the 8. Remove 14 screws (not shown) in locations shown below. gas valve. 9. Disconnect the Spark Electrode, flame sense & stepper motor from the IFC 1. -
Page 91: Gas Maintenance
Gas Maintenance Gas Maintenance Recommended Annual Routine Maintenance for Gas Fireplaces, Stoves and Inserts In order for your Regency appliance to continue to provide comfort to your home periodic maintenance must be performed to ensure it is operating at peak efficiency. The items in the list should be checked by a licensed gas service technician during the annual service check. Your unit may require more frequent maintenance checks if you notice any changes in how it operates. Operational changes to look for can include, but are not limited to, extended start up time, increased fan noise, residue/carbon build up, white build up on the glass/firebox, increased operating noise etc. Should any of these or other conditions arise, discontinue use and schedule a service check with your local licensed gas technician. The list below shows items your licensed service technician will need to check and service at least annually. Clean Inspect Check • Glass • Pilot assembly • Voltage on thermocouple/thermopile (mil- • Interior bricks / panels • Burner livolt models) • Burner ports & burner air shutter • Pressure relief gaskets/doors •... -
Page 92: Parts List
parts list Main Assembly 32, 33, 34, 35, 36, 37, 38, 39 | City Series ACB60E... - Page 93 parts list Main Assembly Part # Description 910-432 Novasit Pilot Tubing With Nuts 686-578/P Valve Assembly -NG 911-039 Two Way Pilot Hood 686-580/P Valve Assembly - LP 911-137 Pilot Hood Clip 904-965 Burner Orifice #32 NG (PO512) W840470 Gasket Pilot Assembly 905-064 Burner Orifice #52 ULPG (PO512) 656-039...
-
Page 94: Accessories
Accessories 948-223 Logo Plate Plastic Regency/Flame Silver 946-634 Glowing Wool Black Sea 6 Gram Part # Description 686-519/P Glass Support Stopper (Set Of 4) 686-900 Steel Stud Framing Kit 936-155 Gasket Tadpole Tape (Sold per 305 mm) 305 mm... - Page 95 notes City Series ACB60E | 95...
-
Page 96: Warranty
FPI Fireplace Products International Ltd. (“the manufacturer”) through its wholly owned subsidiary, Fireplace Products Australia Pty Ltd (for Australia and New Zealand customers) and sold under the Regency® brand of fireplace products (collectively referred to herein as “FPA”), extends this Limited Lifetime Warranty to the original purchaser of this appliance provided the product remains in the original place of installation. - Page 97 Limited Lifetime Warranty. Revision Date: December 2016 Regency Gas Products Warranty City Series ACB60E | 97...
- Page 98 FPI may void this warranty. INCORRECT INSTALLATION OR GAS PRESSURE SETTINGS ARE NOT COVERED BY WARRANTY. A SERVICE OR CALLOUT FEE WILL BE CHARGED IN THESE CIRCUMSTANCES. Revision Date: December 2016 Regency Gas Products Warranty | City Series ACB60E...
- Page 99 (b) Loss means any expense, cost or damage of any kind and includes Consequential Loss and a fine or penalty imposed by a statutory or other authority. Revision Date: December 2016 Regency Gas Products Warranty City Series ACB60E | 99...
- Page 100 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com.au/Customer-Care/Warranty-Registration.aspx...
- Page 101 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
- Page 102 notes 102 | City Series ACB60E...
- Page 103 notes City Series ACB60E | 103...
- Page 104 Dealer Name & Address: _______________________________________________ ___________________________________________________________________ Installer: ____________________________________________________________ Phone #: ___________________________________________________________ Date Installed: _______________________________________________________ Serial No.: __________________________________________________________ Printed in Canada Regency and City Series are trademarks of FPI Fireplace Products International Ltd. © Copyright 2021, FPI Fireplace Products International Ltd. All rights reserved.
