5.1.2.3

Welding parameter ignition time "tZn" diagram

In the ignition time, the wire feed continues to run at creep speed after the arc is ignited; the
ignition behaviour is improved with the optimum setting.
The process described below is always used if there is a pause between welding processes of not less
than 1.5 seconds.
Legend with an explanation of symbols can be found in the MIG/MAG function sequences /
operating modes chapter.
Item No.: 099-004934-EWM01
Functional characteristics
Figure 5-5
Machine control – Operating elements
31
