Chapter 2
RFID CONTROL Menu (SL5000r)
Custom Read Pwr
NOTE: To enable this menu item, set Custom Tag to Enable.
This menu item selects the read power level to be used in the RFID
encoder. 1 is the lowest power level setting, and 20 is the highest.
The default depends on the type of RFID encoder installed in the
printer.
Custom Tag Len
NOTE: To enable this menu item, set Custom Tag to Enable.
This menu item selects the number of bytes in the EPC block within
the RFID tag memory. The default is 12.
Custom EPC Addr
NOTE: To enable this menu item, set Custom Tag to Enable.
This menu item selects the starting location of the EPC block within
the RFID tag memory. The default is 0.
Custom USR Size
NOTE: To enable this menu item, set Custom Tag to Enable.
This menu item selects the size of the USR block within the RFID
tag memory. The default is 0.
Custom USR Addr
NOTE: To enable this menu item, set Custom Tag to Enable.
This menu item selects the starting location of the USR block within
the RFID tag memory. The default is 0.
Custom TID Size
NOTE: To enable this menu item, set Custom Tag to Enable.
This menu item selects the size of the TID block within the RFID tag
memory. The default is 8.
32
