Goodrive800 Pro Series Active Rectifier Hardware Manual
No.
Ethernet interface 1 for
A
PROFINET communication
Ethernet interface 2 for
B
PROFINET communication
PROFINET communication
C
status indicator
PROFINET communication
D
card interface pins
202305 (V1.0)
Name
The PROFINET communication card uses two standard RJ45
interfaces, which do not distinguish the direction and can be
swappable.
Pin
1
2
3
4
5
6
7
8
Used to display faults
(Bus status
indicator)
(System fault
indicator)
(Slave ready
indicator)
(Maintenance
status
indicator)
Used for hard connection with the main control box
Description
Two standard RJ45 interfaces
Function
TX+ Transmit Data+
TX- Transmit Data-
RX+ Receive Data+
n/c Not connected
n/c Not connected
RX- Receive Data-
n/c Not connected
n/c Not connected
LED Color State
LED1 Green -
On
LED2 Blinking
Red
Off
LED3 On
Red
Off
On
LED4
Blinking
Green
Off
LED5
Green -
Description
Description
3.3V power indicator
No network connection
The connection to the network
cable between the PROFINET
controller is OK,
communication is
established.
Communication with
PROFINET controller has been
established.
PROFINET diagnosis exists.
No PROFINET diagnosis.
TPS-1 protocol stack has started.
TPS-1 waits for
initialization.
TPS-1 protocol stack does not
start.
Manufacturer-specific,
depending on the characteristics
of the device.
Expansion card
but the
not
the
