Goodrive800 Pro Series Active Rectifier Hardware Manual
Power supply module
690V
Buffer rectifier bridge
400V
690V
Buffer resistor
400V
690V

2.8.2 Breaker

A breaker can effectively prevent the overload of the variable-frequency equipment and break the fault
current generated by the phase-to-phase or to-ground short circuit, and at the same time it has the function
of isolation so as to avoid electric shock accidents during maintenance.
Note: The breaker should be equipped with an external terminal to controls the opening and closing of the
breaker and a status feedback auxiliary contact!
Power supply module
GD800-91-0615-4-01
GD800-91-0810-4-01
GD800-91-0980-4-01
GD800-91-1168-4-01
GD800-91-1539-4-01
GD800-91-1960-4-01
GD800-91-2336-4-01
GD800-91-3078-4-01
GD800-91-4617-4-01
GD800-91-0369-6-01
GD800-91-0540-6-01
GD800-91-0701-6-01
GD800-91-1026-6-01
GD800-91-1402-6-01
GD800-91-2052-6-01
GD800-91-3078-6-01

2.8.3 AC fuse

An AC fuse protects the rectifier unit and input power cable in case of short circuit, avoiding thermal
overload. See the following table to select AC fuses.
Power supply module
GD800-91-0615-4-01
GD800-91-0810-4-01
GD800-91-0980-4-01
GD800-91-1168-4-01
202305 (V1.0)
Recommended
Rated current
specification
369–1026A 690V 65A
615–1539A 200A, 1600V
369–1026A 200A, 2400V
615–1539A 5Ω, 1000W
369–1026A 5Ω, 1000W
Table 2-5 Breaker model selection
Recommended
Frame size
specification
A8+LCL 690V 800A
A8+LCL 690V 1000A
2* A8+ LCL 690V 1250A
2* A8+ LCL 690V 1600A
2* A8+ LCL 690V 2000A
2*(2* A8+ LCL) 690V 2500A
2*(2* A8+ LCL) 690V 3200A
2*(2* A8+ LCL) 690V 4000A
3*(2* A8+ LCL) 690V 5000A
A8+LCL 690V 400A
A8+LCL 690V 630A
2* A8+ LCL 690V 800A
2* A8+ LCL 690V 1250A
2*(2* A8+ LCL) 690V 1600A
2*(2* A8+ LCL) 690V 2500A
3*(2* A8+ LCL) 690V 4000A
Table 2-6 AC fuse model selection
Frame size
A8+LCL
A8+LCL
2* A8+ LCL
2* A8+ LCL
Recommended model
LC1-D65M7C
3-phase rectifier
MDS200-16
3-phase rectifier
MD200S24M3
Power resistor; 520W; 10Ω
Power resistor; 520W; 10Ω
Recommended breaker
(ABB)
T6 S800
T7 S1000M
T7 S1250M
T7 S1600M
E2.2N2000
E2.2N2500
E4.2N3200
E4.2N4000
E6.2H5000
T5 S400
T5 S630
T6 S800
T7 S1250M
T7 S1600M
E2.2N2500
E4.2N4000
Voltage (V) Current (A)
690V 1000
690V 1250
690V 1600
690V 1000
Product overview
Qty
1
bridge
1
bridge
1
2
2
Qty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Qty
3
3
3
6
13
