5 Rectifier Control Unit (RCU)
5.1 RCU composition
Symbol
Component
1
Indicator
Fiber optic
2
interface
3
Keypad interface Human-machine interface (HMI)
User's wiring
4
terminal
5
Power interface 24V power input terminal
6
Fixed hole
202305 (V1.0)
Figure 5-1 RCU diagram
4
6
Table 5-1 Components
Indicators for the power, run, fault, and status
Fiber optic communication interface
Standard input and output terminals for users
Four fixed holes
1
2
5
Function description
Rectifier Control Unit (RCU)
3
45
