5.4 RST signal detection card

Note:
Models of RST signal detection board: ASY01_PA1112_DT1 (400V), ASY02_PA1112_DT1 (660V).

Note: The RST signal detection board is applicable to Goodrive800 Pro series rectifier control units.

202305 (V1.0)
Terminal
Terminal name
symbol
S2 Digital input 2
S3 Digital input 3
S4 Digital input 4
S5 Digital input 5
S6 Digital input 6
S7 Digital input 7
High-speed pulse
HDI
input
Open collector output
Y1
Open collector output
Y2
H1 Safety input 1
H2 Safety input 2
RO1A NO contact of relay 1
RO1B NC contact of relay 1
Common contact of
RO1C
relay 1
RO2A NO contact of relay 2
RO2B NC contact of relay 2
Common contact of
RO2C
relay 2
RO3A NO contact of relay 3
RO3B NC contact of relay 3
Common contact of
RO3C
relay 3
RO4A NO contact of relay 4
RO4B NC contact of relay 4
Common contact of
RO4C
relay 4
485+
RS485 communication
485-
2. Voltage input range: 12–30V
3. Supporting bidirectional input of NPN and
PNP
High-speed pulse input channel
Max. input frequency: 50kHz
1. Switch capacity: 200mA/30V
1 2. Output frequency range: 0–1kHz
1. Switch capacity: 1A/30V
2 2. Output frequency range: 0–50kHz
It is short connected to COM by default. If
safety input is required, remove the jumpers
between H1 and COM and between H2 and
COM.
1. Contact capacity: AC250V/3A, DC30V/1A
2. Cannot be used as high frequency digital
output
Note: If any input of STO functions H1 and
H2 is valid, RO4 is forced to output, which
can be used as a regular relay usually.
RS485 communication terminals, using the
Modbus protocol
You can choose whether to connect the
120Ω terminal resistor through J5.
