Goodrive800 Pro Series Active Rectifier Hardware Manual
Protective plate A
Protective plate B
202305 (V1.0)
Figure 6-6 Replacing the active rectifier unit
Unit
entry/exit
gulde rail
Disassemble
the (+) and
(-) copper
bars.
Remove
the
connection
cables and
optical
fibers.
Unit
entry/exit
gulde rail
Maintenance and inspection
60
