AD8452 System Demo User Guide

ORDERING INFORMATION

BILL OF MATERIALS

Table 4. Power Module Board
Reference Designator
C1, C2
C3, C4, C8, C13
C7, C9
C10
C11, C12
C14, C15, C16, C17
CL+, CL−, CS+, CS−,
DH_DRV, DL_DRV, EN, SW,
Vin, Vout
D1
D2
F1
J1
J2
J3
L1
L2
Q1
Q2, Q3
Q4, Q6
Q5
R2, R5, R9, R10, R11, R12,
R13, R18, R20
R3, R4
R6
R8
R15
R16
R17, R21
TP1, TP2, TP3, TP4
U1
U2, U3
Table 5. Analog Interface Board
Reference Designator
C1
C2, C3, C5, C8, C9, C11, C14, C19,
C20, C21, C22, C23, C25, C50
C4, C16, C27, C34, C49, C92, C94,
C101, C103, C108
C6, C10, C12, C15
C7
C13
C17
C18
C24, C36, C38, C43, C53, C58, C66,
C67, C69, C71, C72, C74, C76, C77,
C80, C85, C86, C88, C89, C96, C97,
C98, C99, C100, C102
Description
270 µF, 35 V, aluminum-polymer capacitors, radial
10 µF, 50 V, ceramic capacitors, X5R, 1210
10 µF, 25 V, ceramic capacitors, X5R, 0603
0.10 µF, 50 V, ceramic capacitor, X7R, 0603
Capacitor, ceramic, 1000 pF, 50 V, X7R, 0603
150 µF, 10 V, aluminum-polymer capacitors, radial
Test points, PC, multipurpose, red
Diode, Schottky, 30 V, 1 A, SOD123L
Diode, Zener, 15 V, 300 MW, SOD523
Fuse board mount, 10 A, 32 V ac, 63 V dc
8-position header, 0.100" (2.54 mm), gold
12-position header, 0.100" (2.54 mm), gold
16-position header, 0.100" (2.54 mm), gold
6.8 μH high current shielded power inductor
0.16 μH high current shielded power inductor
MOSFET, P-channel, 30 V, 100 A
MOSFETs, N-channel, 30 V, 22 A
MOSFETs, N-channel, 60 V, 320 mA, SOT323
MOSFET, P-channel, 60 V 170 mA, SOT-23
Resistors, SMD, 10 kΩ, 1%, 1/10 W, 0603
Resistors, SMD, 0.0 Ω jumper, 1/10 W, 0603
Resistor, SMD, 71.5 kΩ, 1%, 1/10 W, 0603
Resistors SMD, 10 Ω, 1%, 1/10 W, 0603
Resistors SMD, 0.005 Ω, 1%, 2 W, 2512
Precision current shunt, 0.003 Ω, 0.1%, 15 ppm, 3 W
Resistors, SMD, 2 Ω, 1%, 1/10 W, 0603
Test points, PC, miniature T/H, green
Isolated precision half-bridge driver, 4 A output
IC VREF shunts, ADJ SOT23
Description
1000 µF, 35 V, aluminum capacitor, radial
Capacitor, ceramic, 4.7 μF, 25 V, X5R, 0805
Capacitor, ceramic, 10000 pF, 50 V, NP0, 0603
Capacitor, ceramic, 1 μF, 50 V, X7R, 0805
Capacitor, ceramic, 10 μF, 50 V, X7R, 1210
Capacitor, ceramic, 0.33 μF, 16 V, X7R, 0603
Capacitor, ceramic, 0.047 μF, 50 V, X7R, 0603
Capacitor, ceramic, 680 pF, 50 V, C0G, 0603
Capacitor, ceramic, 0.1 μF, 25 V, X7R, 0603
Manufacturer
Panasonic
Murata
Murata
Murata
Murata
Panasonic
Keystone Electronics
ON Semiconductor
NXP
Schurter Inc.
Sullins Connector
Sullins Connector
Sullins Connector
Coilcraft
Coilcraft
Infineon
Infineon
NXP
Infineon
Yageo
Yageo
Yageo
Yageo
Stackpole Electronics
Vishay Precision Group
Yageo
Keystone Electronics
Analog Devices
Diodes Incorporated
Manufacturer
Panasonic
Taiyo Yuden
Murata
Murata
Murata
TDK Corporation
Murata
TDK Corporation
Murata
Rev. 0 | Page 29 of 32
UG-1181
Part No.
EEH-ZA1V271P
GRM32ER61H106KA12
GRM188R61E106MA73
GRM188R71H104KA93D
GRM188R71H102KA01D
10SVPS150M
5000
MBR130LSFT1G
BZX585-C15
3413.0328.22
PBC04DAAN
PBC06DAAN
PBC08DAAN
XAL1510-682ME
XAL5030-161ME
BSC030P03NS3
BSZ019N03LS
BSS138PW
BSS84PH6433XTMA1
RC0603FR-0710KL
RC0603JR-070RL
RC0603FR-0771K5L
RC0603FR-0710RL
CSNL2512FT5L00
Y14880R00300B9R
RC0603FR-072RL
5116
ADuM7223ACCZ
ZTL431AFTA
Part Number
EEU-FC1V102S
TMK212BJ475KG-T
GRM1885C1H103JA01D
GRM21BR71H105KA12L
GRM32ER71H106KA12L
C1608X7R1C334K080AC
GRM188R71H473KA61D
C1608C0G1H681K080AA
GRM188R71E104KA01D
