Analog Devices AD8452 User Manual page 30

UG-1181
Reference Designator
C26, C33, C39, C40, C44, C48, C51,
C55, C59, C64, C93, C95
C28, C32
C29, C30, C35, C47, C52, C54, C68,
C70, C78, C84, C104, C105, C106,
C107
C31, C42, C45, C65, C73, C75, C79,
C81, C82, C83, C90, C91, C109
C37, C41
C46, C87
C56, C60, C62
C57, C61, C63
D1
D2, D4, D6, D7
D3
D5
D9, D10
D11
F1
F2
J1
J2
J3
J4, J5, J8, J9
J6
J7
L1
L2
MH1, MH2, MH3, MH4
MH1, MH2, MH3, MH4
Q1
Q2, Q6, Q7
Q3
Q4, Q5, Q12, Q13
Q8, Q9, Q10, Q11
R1
R2
R3, R6, R14, R46, R49, R50, R99,
R101, R104
R4, R26, R28, R30, R34, R39, R40,
R47, R48, R51, R57, R60, R70, R73,
R83, R88, R109, R113, R114, R115,
R116, R117, R118, R123, R124,
R138, R152
R5
R7
R8
R9
R10
R11, R12
R13, R17
R15
Description
Capacitor, ceramic, 1000 pF, 50 V, X7R, 0603
Capacitor, ceramic, 270 pF, 50 V, NP0, 0603
Capacitor, ceramic, 1 μF, 25 V, X7R, 0603
Capacitor, ceramic, 100 pF, 50 V, C0G, 0603
Capacitor, ceramic, 2200 pF, 50 V, X7R, 0603
Capacitor, ceramic, 47 pF, 50 V, NP0, 0603
Capacitor, ceramic, 39 pF, 50 V, C0G, 0603
Capacitor, ceramic, 560 pF, 50 V, NP0, 0603
Diode, Zener, 11 V, 200 MW, SOD323F
Green, 573 nm, LEDs, indication - 0603
Diode, Schottky, 60 V, 1 A, POWERDI323
Diode, Zener, 5.1 V, 200 MW, SOD323
Diode, Schottky, 40 V, 3 A, SMB
Diode, Schottky, 30 V, 200 mA, SOD123
Fuse board mount, 200 mA, 125 V ac/dc
Fuse board mount, 375 mA, 125 V ac/dc
8-position header connector, 0.100" (2.54 mm)
12-position header connector, 0.100" (2.54 mm)
16-position header connector, 0.100" (2.54 mm)
Banana jack connectors, standard banana
Terminal block, 2-position side ENT, 3.5 mm
120-position connector receptacle, center strip
contacts, surface mount, gold
Coupled inductor, LPD5030, 100 μH
Fixed inductor, 3.3 μH, 1.2 A, 120 MΩ
Hex standoff threaded M3 × 0.5 brass 0.630"
Machine screw, Pan Phillips M3
Transistor, NPN, 30 V, 2 A, SOT89-3
Transistors, NPN, 40 V, 0.2 A, SOT23
MOSFET, N-channel, 60 V, 4.1 A, 6-TSOP
MOSFET, N-channel, 60 V, 320 mA, SOT323
MOSFET, N-channel, 30 V 22 A, TSDSON-8
Resistor, SMD, 442 Ω, 1%, 1/10 W, 0805
Resistors, SMD, 4.7 kΩ, 1%, 1/10 W, 0603
Resistors, SMD, 0.0 Ω, jumper, 1/10 W, 0603
Resistor, SMD, 4.32 Ω, 1%, 1/8 W, 0805
Resistor, SMD, 294 Ω, 1%, 1/10 W, 0805
Resistor, SMD, 49.9 kΩ, 1%, 1/10 W, 0603
Resistor, SMD, 205 kΩ, 1%, 1/10 W, 0603
Resistor, SMD, 23.2 kΩ, 1%, 1/10 W, 0603
Resistors, SMD, 26.7 kΩ, 1%, 1/10 W, 0603
Resistors, SMD, 2.43 kΩ, 1%, 1/10 W, 0603
Resistor, SMD, 8.87 kΩ, 1%, 1/10 W, 0603
Rev. 0 | Page 30 of 32
AD8452 System Demo User Guide
Manufacturer Part Number
Murata GRM188R71H102KA01D
Murata GRM1885C1H271JA01D
Murata GRM188R71E105KA12D
TDK Corporation C1608C0G1H101J080AA
Murata GRM188R71H222KA01D
AVX Corporation 06035A470JAT2A
TDK Corporation CGA3E2C0G1H390J080AA
Murata GRM1885C1H561JA01D
Fairchild MM3Z11VB
Semiconductor
OSRAM Opto LG Q396-PS-35
Diodes Incorporated PD3S160-7
Diodes Incorporated DDZ9689S-7
Diodes Incorporated B340LB-13-F
ON Semiconductor BAT54T1G
Littelfuse Inc. 0466.200NR
Littelfuse Inc. 0466.375NR
Sullins Connector PPPC042LFBN-RC
Sullins Connector PPPC062LFBN-RC
Sullins Connector PPPC082LFBN-RC
Johnson-Cinch 108-0740-001
Connectivity
TE Connectivity AMP 1776275-2
Hirose Electric Co Ltd FX8-120S-SV(21)
Coilcraft LPD5030-104MRB
Murata LQH32PN3R3NN0L
Harwin Inc. R30-1011602
B&F Fastener Supply MPMS 003 0008 PH
Diodes Incorporated 2DD2679-13
ON Semiconductor MMBT3904LT1G
Vishay Siliconix SI3458BDV-T1-E3
NXP Semiconductors BSS138PW,115
Infineon Technologies BSZ019N03LS
DNI (Do Not Install)
Vishay Dale CRCW0805442RFKEA
Vishay Dale CRCW06034K70FKEA
Vishay Dale CRCW06030000Z0EA
Vishay Dale CRCW08054R32FKEA
Vishay Dale CRCW0805294RFKEA
Vishay Dale CRCW060349K9FKEA
Vishay Dale CRCW0603205KFKEA
Vishay Dale CRCW060323K2FKEA
Vishay Dale CRCW060326K7FKEA
Vishay Dale CRCW06032K43FKEA
Vishay Dale CRCW06038K87FKEA
