AD8452 System Demo User Guide
Reference Designator
R16
R18
R19, R42, R44, R45, R52, R53, R55,
R62, R77, R80, R85, R128, R129, R132,
R133, R137, R148, R149, R151
R20, R23, R122
R24, R35
R25, R31, R32, R33, R72, R139,
R140
R27, R36
R29, R68, R84, R86, R87, R89, R90,
R93, R94, R95, R96, R100, R102,
R103, R107, R108, R110, R111,
R112, R141, R142
R37, R41, R144, R145
R43
R61
R63, R71, R76
R64, R66, R74
R65
R67, R69, R75
R81
R82
R91, R92, R97, R98
R105, R106
R125
R126
R130, R131
R134, R135
R136
R143
R150
TP1, TP2, TP4, TP5, TP8, TP9, TP15,
TP16
TP3, TP11, TP12, TP14, TP19, TP26,
TP27, TP29
TP6, TP7, TP10, TP13. TP20, TP21,
TP22, TP23, TP24, TP25, TP28, TP30
U1
U2
U3
U4
U5
U6
U7
U8
U9
U10
U11, U17
U12, U14
U13, U15
U16
Description
Resistor, SMD, 88.7 kΩ, 1%, 1/10 W, 0603
Resistor, SMD, 0.0 Ω, jumper, 1/8 W, 0805
Resistors, SMD, 10 kΩ, 1%, 1/10 W, 0603
Resistors, SMD, 100 kΩ, 1%, 1/10 W, 0603
Resistors, SMD, 6.04 kΩ, 1%, 1/10 W, 0603
Resistors, SMD, 1 kΩ, 1%, 1/10 W, 0603
Resistors, SMD, 64.9 kΩ, 1%, 1/10 W, 0603
Resistors, SMD, 33 Ω, 1%, 1/10 W, 0603
Resistors, SMD, 100 Ω, 1%, 1/10 W, 0603
Resistor, SMD, 4.42 kΩ, 1%, 1/10 W, 0603
Resistor, SMD, 54.9 kΩ, 1%, 1/10 W, 0603
Resistors, SMD, 6.65 kΩ, 1%, 1/10 W, 0603
Resistors, SMD, 121 kΩ, 1%, 1/10 W, 0603
Resistor, SMD, 4.02 kΩ, 1%, 1/4 W, 0603
Resistors, SMD, 78.7 kΩ, 1%, 1/10 W, 0603
Resistor, SMD, 825 Ω, 1%, 1/10 W, 0603
Resistor, SMD, 35.7 kΩ, 1%, 1/10 W, 0603
Resistors, SMD, 10 kΩ, 0.1%, 1/16 W, 0603
Resistors, SMD, 4.99 kΩ, 0.1%, 1/16 W, 0603
Resistor, SMD, 3.32 kΩ, 1%, 1/8 W, 1206
Resistor, SMD, 2.61 kΩ, 1%, 1/8 W, 1206
Resistors, SMD, 499 Ω, 1%, 1/10 W, 0603
Resistors, SMD, 1 MΩ, 1%, 1/10 W, 0603
Resistor, SMD, 39.2 kΩ, 1%, 1/10 W, 0603
Resistor, SMD, 133 kΩ, 1% 1/10 W, 0603
Resistor, SMD, 243 kΩ, 1%, 1/10 W, 0603
Test points PC mini, .040" D, red
Test points PC mini, .040" D, green
Test points PC mini, .040" D, white
IC, regulator, LDO ADJ, 0.3 A, 8-lead SOIC
IC, regulator, BST SEPIC ADJ, 1.4 A, 8-lead MSOP
IC, regulator, LDO, 5 V, 0.3 A, 8-lead SOIC
IC, regulator, switched capacitor inverter,
25 mA, 6-lead SOT23
IC EEPROM, 32 kb, 400 kHz, 8-lead SOIC
IC DAC, 16 bit, SRL, 16-lead TSSOP
Battery charge controller, PWM, IC, 48-lead LQFP
IC comparator, dual OD, 8-lead SOT23
IC, op amp, JFET, 5 MHz, 8-lead SOIC
IC ADC 8-channel mux, low power, 40-lead LFCSP
IC comparator. open-drain, 5-lead SC70
IC gate AND, 1-channel, 2-input, SOT-23
IC inverter, SGL TinyLogic SOT-23
IC VREF series, 5 V, 8-lead SOIC
Rev. 0 | Page 31 of 32
Manufacturer Part Number
Vishay Dale CRCW060388K7FKEA
Vishay Dale CRCW08050000Z0EA
Vishay Dale CRCW060310K0FKEA
Vishay Dale CRCW0603100KFKEA
Vishay Dale CRCW06036K04FKEA
Vishay Dale CRCW06031K00FKEA
Vishay Dale CRCW060364K9FKEA
Vishay Dale CRCW060333R0FKEA
Vishay Dale CRCW0603100RFKEA
Vishay Dale CRCW06034K42FKEA
Vishay Dale CRCW060354K9FKEA
Vishay Dale CRCW06036K65FKEE
Vishay Dale CRCW0603121KFKEA
Vishay Dale CRCW06034K02FKEA
Vishay Dale CRCW060378K7FKEA
Vishay Dale CRCW0603825RFKEA
Vishay Dale CRCW060335K7FKEA
TE Connectivity RN73C1J10KBTG
TE Connectivity RN73C1J4K99BTDF
Vishay Dale CRCW12063K32FKEA
Vishay Dale CRCW12062K61FKEA
Vishay Dale CRCW0603499RFKEA
Vishay Dale CRCW06031M00FKEA
Vishay Dale CRCW060339K2FKEA
Vishay Dale CRCW0603133KFKEA
Vishay Dale CRCW0603243KFKEA
Keystone Electronics 5000
Keystone Electronics 5116
Keystone Electronics 5002
Analog Devices ADP7102ARDZ-R7
Analog Devices ADP1612ARMZ-R7
Analog Devices ADP7102ARDZ-5.0-R7
Analog Devices ADM8829ARTZ-REEL7
Microchip Technology 24LC32A-I/SN
Analog Devices AD5689RBRUZ
Analog Devices AD8452ASTZ
Analog Devices ADCMP343YRJZ-REEL7
Analog Devices ADTL082ARZ
Analog Devices AD7173-8BCPZ
Analog Devices ADCMP370AKS
Fairchild/ON Semi NC7SZ08M5X
Fairchild/ON Semi NC7SZ04M5X
Analog Devices ADR4550BRZ
UG-1181
