Maintenance / servicing

6.5 Troubleshooting

Problem Cause
1. Incorrect electrical hook-up (2 phases).
Pump does not
2. Wrong rotational direction.
deliver or deliv-
ers at a reduced
3. Air in the suction line or in the pump.
rate.
4. Back pressure too high.
5. Suction head too high, NPSH feed too low.
6. Lines clogged or foreign material in the
impeller.
7. Air inclusions as a result of a defective
seal.
1. Pump jammed because of clogging.
Motor safety
2. Pump jammed by contact because pump
switch turns
body was twisted by the pipelines. (Check
motor off. Motor
for damage).
is overloaded.
3. Pump continues to run beyond the rated
operating point.
4. The density or viscosity of the pumping
medium is higher than the value stated in
the order.
5. Motor safety switch not properly adjusted.
6. Motor running on 2 phases.
1. Suction head too high, NPSH feed too low.
Pump produces
too much noise.
2. Air in the suction line or in the pump.
Pump runs
3. Back pressure lower than stated.
roughly and
4. Impeller out of balance.
vibrates.
5. Internal parts worn.
6. Pump is twisted (causing contact noises).
Check for damage.
7. Bearings are defective.
8. Bearings have too little, too much, or the
wrong kind of lubricant.
9. Motor cooling fan defective.
10. Gear ring of the coupling (power transmis-
sion) defective.
11. Foreign material in the pump.
Table 7 Troubleshooting
BA.017.BYY.001.01.10.GB
a
a
b
Remedy
1. Check the electrical connections and cor-
rect them if necessary.
2. Reverse the phases of the power supply
(reverse the polarity).
3. Vent the suction line or the pump and refill.
4. Reset the operating point according to the
data sheet. Check system for contamina-
tion.
5. Raise the liquid level on the suction side.
Open the shut-off valve in the suction line
all the way.
Produce the conditions described in 3.3,
page 13. Consult manufacturer.
6. Open the pump and fix the problem.
7. Check the pipeline seals, the pump hous-
ing seals, and the shaft seals. Replace if
necessary.
1. Open the pump and fix the problem.
2. Install the pump so that there is no stress
on it. Support the pipelines at fixed points.
3. Set the operating point according to the
data sheet.
4. If it is acceptable for the performance to be
lower than that stated, decrease the deliv-
ery rate on the pressure side. Otherwise,
use a more powerful motor.
Consult manufacturer.
5. Check the setting. Replace the safety
switch if necessary.
6. Check the electrical connections. Replace
defective fuses.
1. Raise the liquid level on the suction side.
Open the shut-off valve in the suction line
all the way.
Produce the conditions described in Sec-
tion 3.3, page 13. Consult manufacturer.
2. Vent the suction line or the pump and refill.
3. Set the operating point according to the
data sheet.
4. Clean, inspect, and rebalance the impeller.
5. Replace parts.
6. Install the pump so that there is no stress
on it. Support the pipelines at fixed points.
7. Replace the bearings.
8. Add more lubricant, decrease the amount,
or replace the lubricant.
9. Replace the motor cooling fan.
10. Replace the gear ring of the coupling. Rea-
lign the coupling.
11. Open the pump and clean it (install a
screen in front of self-priming pumps, if
necessary).
