UG-171

ORDERING INFORMATION

BILL OF MATERIALS

Table 2.
Reference Designator
C1
C2
C3
C4, C6, C10
C5, C7, C9, C11, C13
C8, C12
C14, C15
C16, C17, C18, C19
C20, C23
C21, C24
C22, C25
C26, C27
D1
D2
D3, D5
D4
J1
J2
J3, J4, J10
J5, J6, J7, J8, J9
J11
LK1, LK3, LK4, LK5
LK2
GND
VSUPPLY
R1A
R1
R2
R3
R4, R5, R6, R23, R29, R42
R7, R8, R9
R10
R11
R12, R13, R24, R25, R26
R14, R16, R18, R28, R36
R15, R17, R22, R27, R32, R33, R37, R46
R19, R20
R21
R30
R31, R34
S1
T1 to T14
U1
U3
U2
U4
Y1
Y2
Downloaded from Elcodis.com electronic components distributor
Part Description
Capacitor, 0805, 680 pF
Capacitor, 0805, 10 nF
Capacitor, 0805, 270 pF
Capacitor, 0402, 0.1 μF, 16 V
Capacitor, 0603, 10 pF, 50 V, SMD
Capacitor, Case A, 22 μF, 6.3 V
Capacitor, 0603, 1 nF, 50 V
Capacitor, 0603, 100 pF, 50 V
Capacitor, Case A, 1 μF, 16 V
Capacitor, 0603, 10 nF, 50 V
Capacitor, Case A, 4.7 μF, 10 V
Capacitor, 0603, 10 nF, 50 V
LED, green
Diode, DO41, 1 A, 50 V
SD103C, 6.2 V
LED, red
120-way connector, 0.6 mm pitch
Jack, SMA, SMA_EDGE
JACK SMA receptacle straight PCB
Jack, SMA, SMA_EDGE
Jack SMA receptacle straight PCB
Jumper2\SIP3, Link-3P
Jumper-2
Black 4 mm banana socket
Red 4 mm banana socket
Resistor, 0805
Resistor, 0805, 2.4 kΩ
Resistor, 0805, 5.1 kΩ
Resistor, 0805, 5.1 kΩ, ±1%, 0.1 W
Resistor, 0603, 330 Ω
Resistor, 0603, 18 Ω
Resistor, 0603, 51 Ω
Resistor, 0603 100 Ω
Resistor, 0603, 10 kΩ
Resistor, 0603, 0 Ω
Resistor, 0603, 0 Ω
Resistor, 0603, 330 kΩ, ±1%, 0.063 W
Resistor, 0603, 4.7 kΩ, ±1%, 0.063 W
Resistor, 0402
Resistor, RC31, 0402, 100 kΩ
Switch, PCB, SPDT, 20 V
Test point, PCB, red PK_100
16-lead TSSOP ADF4156
6-lead SOT-23 ADP3300
6-lead SOT-23 ADP3300
32k I 2 C serial EEPROM, MSOP8
VCO V940ME03
Low profile/temperature compensated
crystal oscillator, OSC_TCXO, 10 W
Rev. B | Page 20 of 24
Evaluation Board User Guide
Manufacturer/Part No.
PHYCOMP 2238 861 15681
MURATA GRM2195C1H103JA01D
PHYCOMP 2238 861 15271
AVX CM105X7R104K16AT
AVX 06035A100JAT2A
AVX TAJA226K006R
AVX 06035A102JAT2A
AVX 06035A101JAT2A
AVX TAJA105K016R
AVX 06035C103JAT2A
AVX TAJA475K010R
Not inserted
OSRAM LGR971-Z
Multicomp 1N4001
ON Semiconductor MBR0520LT1G
Avago HSMS-C170
Hirose FX8-120S-SV(21)
Johnson Components 142-0701-851
Not inserted
Not inserted
Pomona 72963
Harwin M20-9990345 and M7566-05
Harwin M20-9990245 and M7566-05
Deltron 571-0100-01
Deltron 571-0500-01
User supplied
MULTICOMP MC 0.1W 0805 1% 2K4
MULTICOMP MC 0.1W 0805 1% 5K1
Multicomp MC 0.1 0805 1% 5K1
Multicomp MC 0.063W 0603 1% 330R
Multicomp MC 0.063W 0603 1% 18R
Multicomp MC 0.063W 0603 1% 51R
Multicomp MC 0.0625W 0402 1% 100R
Multicomp MC 0.063W 0603 1% 10K
Multicomp MC 0.063W 0603 1% 0R
Not inserted
Multicomp MC 0.063W 0603 1% 330K
Multicomp MC 0.063W 0603 1% 4K7
Not inserted
YAGEO (Phycomp) RC0402JR-07100KL
APEM TL36P0050
Vero 20-313137
ADF4156BRUZ
ADP3300ART-5
ADP3300ART-3
Microchip 24LC32A-I/MS
Z-Communications V940ME03
Fox 801-BELF
