UG-1526

HARDWARE SETUP

CONFIGURATION 1

Use the external signal generator as the clock source as follows:
1.
Remove the jumper on JP1.
2.
Connect a low phase noise, high frequency clock source to
the J31 subminiature Version A (SMA) connector.
3.
Set the output level to 0 dBm.
4.
Connect a second low phase noise, high frequency clock
source (10 MHz to 250 MHz) with a 0 dBm output level
that is the reference clock of the
connector.
5.
Synchronize the two clock sources. A unit (such as the
Rohde & Schwarz SMA100) has a convenient option for a
secondary signal source. Using this option ensures that the
two clocks are synchronized. The 10 MHz reference output
of the signal generator can also be used as the reference input.
6.
Connect the spectrum analyzer to the J32 SMA connector.
7.
Connect the evaluation board to the FMC connector of the
ADS7-V2EBZ.
Figure 4. View of the Top of the
ADF4355
to the J61 SMA
ADS7-V2EBZ
Pattern Generator Board
AD9161/AD9162/AD9163/AD9164

CONFIGURATION 2

Use the on-board
1.
Put the jumper on JP1 (on the evaluation board).
2.
Connect the spectrum analyzer to the J32 SMA connector.
3.
Connect the evaluation board to the FMC connector of the
ADS7-V2EBZ.
4.
Connect the ac adapter to the ADS7-V2EBZ.
5.
Press the power switch on the
both boards.
CONFIGURATION 3: DC TEST/NCO MODE
WITHOUT
ADS7-V2EBZ
AD9162
AND AD9164)
The
AD9162 andAD9164
without the ADS7-V2EBZ. However, the devices need to run
from an external power supply.
In this case, do not connect the evaluation board to the
V2EBZ. Instead, complete the following steps:
1.
Connect a 12 V dc supply to TP41 (red) and GND to TP64
(black) on the evaluation board. The external power
supply must have capacity for 1 A of current.
2.
Put the jumper on JP1 if using the on-board
the clock source. If using an external clock source, connect
a low phase noise, high frequency clock source to J31.
3.
Connect the spectrum analyzer to the J32 SMA connector.
Rev. 0 | Page 4 of 22
ADF4355
as the clock source as follows:
ADS7-V2EBZ
(ONLY AVAILABLE FOR
can work in dc test/NCO mode
User Guide
to power on
ADS7-
ADF4355
as
