AD9161/AD9162/AD9163/AD9164

EVALUATION BOARD SOFTWARE

The evaluation board software provides an easy to use graphical
user interface called analysis, control, evaluation (ACE).
included on the evaluation board DVD and is available at
www.analog.com/EVAL-AD916X.
From the DVD, install the AD9161
interface (SPI) programmer application. Also, from the DVD
(or from wiki.analog.com as a part of the DAC software suite),
install the DPGDownloader™. Use this program for loading
vectors into the ADS7-V2EBZ.
OPTIONAL 12V
SUPPLY
USB
USB
ADS7-V2EBZ
J32: DAC OUTPUT
J31: EXTERNAL CLOCK
J61: ADF4355
REF CLOCK
J62: ADF4355 OUTPUT
User Guide
ACE is
series ACE serial peripheral
TP41 AND
TP64
XP2
SYSREF±
FPGA REF
P1
JESD204B
Figure 2. Block Diagram of the Evaluation Board Lab Bench Setup
Figure 3. Evaluation Board: Top Side
Rev. 0 | Page 3 of 22
The ACE SPI programmer application enables full access to the
register map of the AD9161, AD9162, AD9163, and AD9164,
and has additional functionality, such as the ability to record,
load, and save macros, or register sequences, to ease
programming of the device.
The ADF4355 and
macros or register sequences are included in this user guide to
demonstrate the usefulness of the function and to set up the
device. ACE also controls the SPDT switch for selecting the
clock source.
OPTIONAL
EXTERNAL
REFERENCE
J61
CRYSTAL
OSCILLATOR
ADF4355
÷4
SYSREF±
AD9508
HIGH SPEED
XP2: USB
AD9508 are also configured by ACE. Several
OPTIONAL
DAC
CLOCK
J31
HMC849A
J32 SPECTRUM
ANALYZER
DAC
FMC CONNECTOR
Y61: CRYSTAL
BOARD VERSION
J1: CRYSTAL
POWER JUMPER
TP41: 12V POWER
TP64: GND
UG-1526
